The ASAHI AV SRH-007 / TA2A-063D-00 is a heavy-duty industrial pneumatic ball valve engineered for reliable quarter-turn shutoff and tight fluid control in demanding process systems. This assembly combines the SRH-007 pneumatic actuator with the TA2A-063D-00 true-union ball valve body, providing a compact, corrosion-resistant solution for automated isolation of compatible media.
ASAHI AV SRH-007 / TA2A-063D-00 Technical Specifications
| Valve Type | Pneumatic Ball Valve (True Union) |
|---|---|
| Actuator Model | SRH-007 |
| Valve Body Model | TA2A-063D-00 |
| Actuation | Pneumatic, double-acting or spring-return (per configuration) |
| Body Material | PVC or CPVC (typical ASAHI AV thermoplastic) |
| Seal Material | PTFE / EPDM / FKM (application-dependent) |
| Port Connection | True union socket or threaded (per model) |
| Control Media | Air or inert gas |
| Mounting | Integrated actuator-to-valve bracket |
Key Engineering Features
- Pneumatic quarter-turn actuation for fast, repeatable on/off control
- True union design allows inline maintenance and quick replacement
- Corrosion-resistant thermoplastic construction for aggressive fluid service
- Precision-machined ball and seats ensure low torque and bubble-tight sealing
- Compact SRH-007 actuator with visual position indicator
- Compatible with standard pneumatic control accessories (solenoid pilot, limit switch)
Industrial Applications
- Chemical processing and dosing systems
- Water and wastewater treatment
- Semiconductor and electronics manufacturing
- Food and beverage fluid handling
- Pharmaceutical and biotech process lines
- General industrial automation and OEM equipment
For technical inquiries, dimensional drawings, or replacement support for ASAHI AV SRH-007 / TA2A-063D-00, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
ASAHI AV SRH-007 / TA2A-063D-00 Pneumatic Ball Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the ASAHI AV SRH-007 / TA2A-063D-00 Pneumatic Ball Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
