Product Overview
The ASCO VCEFCM8314G301 is a high-performance industrial solenoid valve engineered by ASCO (Emerson) for precise control of neutral gases and liquids in demanding process environments. Featuring a robust 4-way, 2-position spool-type configuration, this valve is designed to direct flow with rapid response times and high cycle reliability. Its construction is optimized for pneumatic and light hydraulic process circuits, offering dependable actuation in automated systems where consistent directional control is critical. The VCEFCM series is recognized for its durable coil insulation, corrosion-resistant body materials, and leak-tight sealing, making it a preferred choice for OEM and MRO applications across global industries.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Valve – Process & Pneumatic Solenoid Valve |
| Model Designation | VCEFCM8314G301 |
| Valve Function | 4-Way, 2-Position (Spool Type) |
| Operating Pressure | Standard Industrial Grade (Up to 10 bar / 145 psi) |
| Port Size & Connection | 1/4″ NPT (Standard ISO Interface) |
| Voltage / Coil Rating | 24V DC (Standard Industrial Coil) |
| Body Material | Brass / Stainless Steel (Corrosion Resistant) |
| Seal Material | NBR / FKM (High Compatibility) |
Engineering Features & Advantages
- Precision Spool Actuation: The balanced spool design ensures minimal pressure drop and precise flow metering, enabling accurate directional control in complex pneumatic circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a high cycle life and resistance to vibration and thermal stress.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original ASCO OEM standards, ensuring drop-in installation without modification.
- Fast Response Time: Optimized solenoid and spring return mechanism delivers rapid shifting, reducing cycle times in automated process lines.
- Leak-Tight Sealing: Precision-machined sealing surfaces and high-quality elastomers prevent internal and external leakage, maintaining system efficiency.
Typical Industrial Applications
This solenoid valve is widely used in plastic injection molding machines for mold opening/closing and ejection control, metallurgical presses for clamping and ram direction, packaging and food processing lines for actuator sequencing, and CNC machine tools for tool changer and coolant diversion. It is also suitable for marine and construction hydraulic pilot circuits where reliable directional control of air or light oil is required.
PRODUCT IMAGES
ASCO VCEFCM8314G301 Solenoid Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine ASCO VCEFCM8314G301 Solenoid Valve. This USA-made 24V DC hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
