The AVENTICS 5652010000 is a heavy-duty industrial pneumatic solenoid valve engineered for precise directional control of compressed air in demanding automation and process systems. This 5/2-way valve features a robust spool design and a wet-pin armature solenoid, ensuring rapid response and long service life under continuous duty cycles.
AVENTICS 5652010000 Technical Specifications
| Function | 5/2-way, single solenoid, spring return |
|---|---|
| Actuation | Electrical solenoid (wet-pin armature) |
| Port Size | 1/4″ NPT (or G1/4 depending on variant) |
| Operating Pressure | 2 to 10 bar (29 to 145 psi) |
| Flow Rate | 1200 l/min (at 6 bar, Δp=1 bar) |
| Voltage | 24 V DC (other voltages available) |
| Power Consumption | 2.5 W (DC) |
| Body Material | Anodized aluminum |
| Seal Material | NBR (Buna-N) |
| Mounting | Inline or manifold (CETOP/ISO 15407-1) |
| Protection Class | IP65 (with properly installed connector) |
| Temperature Range | -10°C to +50°C (14°F to 122°F) |
Key Engineering Features
- Wet-pin armature design eliminates dynamic seals, reducing friction and wear for extended solenoid life.
- High flow capacity with minimal pressure drop ensures efficient actuator response.
- Manual override (non-locking) standard for easy commissioning and troubleshooting.
- Compact, lightweight aluminum body suitable for space-constrained installations.
- Compatible with a wide range of AVENTICS manifolds and sub-bases for flexible system integration.
Industrial Applications
- Packaging and material handling machinery
- Automotive assembly and testing lines
- Food and beverage processing (with appropriate air preparation)
- General factory automation and robotic end-effectors
- Textile, printing, and woodworking equipment
For technical inquiries, dimensional drawings, or replacement support for AVENTICS 5652010000, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
AVENTICS 5652010000 Pneumatic Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the AVENTICS 5652010000 Pneumatic Solenoid Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
