Product Overview
The AVENTICS R412010956 / DM2CDA66A21 is a pneumatically actuated directional control valve from the AVENTICS Series DM2C (Titanium / ISO 15407-1 compliant) platform. It functions as a 5/2-way spool valve, using a pilot air signal to shift the internal spool and redirect compressed air flow between ports for extend/retract or open/close actuation of downstream pneumatic cylinders and actuators. Engineered for high-cycle industrial duty, the DM2C series is designed for reliable spool actuation, fast response, and consistent flow characteristics in automated process and factory systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Directional Control Valve (5/2-way spool valve) |
| Model Designation | R412010956 / DM2CDA66A21 |
| Manufacturer | AVENTICS (Emerson) |
| Valve Function | 5/2-way, pilot actuated, spring return |
| Operating Pressure | Standard pneumatic range (approx. 2–10 bar, per Series DM2C rating) |
| Actuation Type | Pneumatic pilot (external pilot air signal) |
| Mounting & Connection | ISO 15407-1 / AVENTICS interface, sub-base or manifold mounting |
| Seal Material | NBR / nitrile (standard industrial pneumatic sealing) |
Engineering Features & Advantages
- Precision Spool Metering: The 5/2-way spool design provides accurate flow direction control with minimal pressure drop, ensuring repeatable actuator motion in automated sequences.
- Fast Pilot Response: Pneumatic pilot actuation delivers rapid spool shifting for high-cycle automation, reducing machine cycle times and improving throughput.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust spool and seal construction resistant to wear and contamination.
- Direct Fit Replacement: Exact dimensional and functional compatibility with AVENTICS Series DM2C and ISO 15407-1 manifold standards, allowing drop-in replacement without modification.
Typical Industrial Applications
This AVENTICS directional control valve is commonly deployed in automated pneumatic systems such as plastic injection molding machines (mold clamping and ejection circuits), packaging and assembly lines (pick-and-place actuators), CNC machine tool automation (tool changers, clamping), and general factory process control (material handling, sorting, and actuation of pneumatic cylinders and rotary actuators).
PRODUCT IMAGES
AVENTICS R412010956 / DM2CDA66A21 Pneumatic Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine AVENTICS R412010956 / DM2CDA66A21 Solenoid Directional Control Valve. This German-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
