Product Overview
The AXXON MDS3200 Micro Dispensing Valve is a precision-engineered pneumatic dispensing valve designed for controlled micro-deposition of adhesives, sealants, lubricants, and low-to-medium viscosity fluids in automated industrial processes. Manufactured by AXXON, this valve utilizes a pneumatically actuated spool and nozzle assembly to deliver repeatable, high-accuracy shot volumes down to the microliter range. Unlike hydraulic pumps, the MDS3200 operates as a process valve, functioning as the critical control element between a pressurized fluid reservoir and the dispensing point. Its compact body, fast cycle response, and fine-tuned needle stroke adjustment make it a preferred choice for high-speed automated dispensing lines where deposit consistency and minimal dead volume are essential.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Process & Pneumatic Dispensing Valve |
| Model Designation | MDS3200 |
| Operating Pressure | Standard Industrial Grade (Up to rated bar) |
| Mounting & Connection | Standard ISO / Manufacturer Interface |
Engineering Features & Advantages
- Precision Performance: Pneumatically actuated needle-and-seat design delivers highly repeatable micro-shot volumes with minimal pulse and drip, ensuring deposit consistency across high-speed dispensing cycles.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with wear-resistant wetted components and a robust valve body suited to demanding automated production environments.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, allowing drop-in integration into existing AXXON dispensing systems and standard mounting brackets.
Typical Industrial Applications
The AXXON MDS3200 is widely deployed in electronics PCB assembly and underfill dispensing, automotive component bonding and gasketing, medical device micro-adhesive application, and precision assembly lines within CNC machine tool and plastic injection molding operations where accurate, repeatable micro-deposition of process fluids is critical to product quality and throughput.
PRODUCT IMAGES
AXXON MDS3200 Micro Dispensing Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine AXXON MDS3200 Solenoid Directional Spool Valve. This German-made 24V DC hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
