Product Overview
The BIFOLD FP06P-S1-04-32-NU-V-77A-24D-NL-30 is a high-performance pneumatic directional control valve engineered by BIFOLD, a globally recognized brand in fluid power and process control technology. This valve operates on a spool-actuated design, utilizing a solenoid pilot interface to shift an internal spool mechanism, thereby directing compressed air flow between ports to control the extension and retraction of pneumatic actuators, cylinders, and rotary devices. As a critical component in automated industrial systems, it provides precise, repeatable switching logic for demanding process environments. The model designation indicates a 4-way, 2-position or 3-position configuration (as inferred from the “04” and “32” codes) with a nominal port size of 1/4″ or 3/8″ (depending on the specific series interpretation), a 24V DC solenoid coil (“24D”), and a manual override (“NL” typically denotes a non-locking manual operator). This valve is designed for panel or manifold mounting, ensuring seamless integration into centralized pneumatic control cabinets and valve islands.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Directional Control Valve (Spool Type) |
| Model Designation | FP06P-S1-04-32-NU-V-77A-24D-NL-30 |
| Operating Pressure | Standard Industrial Grade (Up to 10 bar / 145 psi) |
| Mounting & Connection | Standard ISO 15407-1 / Namur Interface (Manifold or Sub-base Mounted) |
| Actuation Method | Solenoid Pilot Actuated (24V DC) with Manual Override |
| Valve Function | 4-Way, 2-Position (Single Solenoid) or 3-Position (Spring Centered) |
| Port Size | 1/4″ or 3/8″ NPT / G (Based on FP06 Series Standard) |
| Seal Material | Nitrile (NBR) / Polyurethane (Standard Industrial Air Service) |
Engineering Features & Advantages
- Precision Spool & Sleeve Assembly: The valve features a hardened, precision-ground spool and sleeve mechanism that ensures minimal internal leakage, fast response times, and consistent shifting even under varying pressure differentials. This design is critical for accurate metering and rapid cycling in automated assembly lines.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, the FP06P series housing is constructed from high-grade anodized aluminum or die-cast alloy, providing excellent corrosion resistance and mechanical durability against vibration and thermal cycling.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original BIFOLD standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
As a critical component in automated industrial systems, it provides precise, repeatable switching logic for demanding process environments.
PRODUCT IMAGES
BIFOLD FP06P-S1-04-32-NU-V-77A-24D-NL-30 Pneumatic Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine BIFOLD FP06P-S1-04-32-NU-V-77A-24D-NL-30 Solenoid Directional Valve. This UK-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
