Product Overview
The Bürkert 00313806 is a direct-acting 2/2-way solenoid valve engineered for precise control of neutral and slightly aggressive media in industrial process and pneumatic systems. As part of Bürkert’s proven Type 6013 series, this valve features a compact brass body with an encapsulated solenoid coil, delivering reliable on/off fluid control without requiring a minimum differential pressure. The 00313806 is designed for direct mounting in pipelines and manifolds, making it an ideal drop-in solution for OEM and MRO applications where space, response time, and sealing integrity are critical. Its robust construction and FKM (Viton) seal material ensure compatibility with a wide range of media including compressed air, water, oils, and select chemical solutions.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | 2/2-Way Direct-Acting Solenoid Valve |
| Model Designation | Bürkert 00313806 (Type 6013 Series) |
| Operating Pressure | 0 to 10 bar (0 to 145 psi) — direct-acting, no minimum pressure required |
| Orifice Size | 2.0 mm (standard for this model code) |
| Body Material | Brass (CuZn) |
| Seal Material | FKM (Viton) — suitable for air, water, oils, and neutral media |
| Coil Voltage | 24V DC (standard; other voltages available on request) |
| Power Consumption | Approx. 8W (DC coil) |
| Port Connection | G 1/4″ threaded ports (ISO 228/1) |
| Mounting & Connection | Inline threaded mounting; DIN 43650 plug connector |
| Response Time | Fast opening/closing (typically 10–20 ms) |
| Protection Class | IP65 (with properly installed cable plug) |
Engineering Features & Advantages
- Precision Performance: The 2/2-way direct-acting solenoid valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Precision-manufactured to original BURKERT specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings of 0 to 10 bar (0 to 145 psi) — direct-acting, no minimum pressure required, supporting stable operation across the full working range.
Typical Industrial Applications
The 00313806 is designed for direct mounting in pipelines and manifolds, making it an ideal drop-in solution for OEM and MRO applications where space, response time, and sealing integrity are critical.
PRODUCT IMAGES
BURKERT 00313806 Solenoid Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine BURKERT 00313806 Solenoid Valve. This Germany-made 24V DC hydraulic component features a direct-acting design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
