Product Overview
The Bürkert Type 2030 A 15,0 EA (Part No. 00154770) is a pneumatically actuated 2/2-way diaphragm valve engineered for neutral and aggressive media in process and industrial fluid control systems. Manufactured by Bürkert, a global leader in fluid control technology, this valve utilizes a pneumatically driven piston actuator acting on an elastomeric diaphragm to isolate the process media from the actuator and environment. With a nominal line size of DN 15 (15,0), the valve delivers reliable on/off shut-off and is ideally suited for hygienic, corrosive, or high-purity applications where contamination-free flow control and leak-tight sealing are essential. Its robust construction and modular design make it a preferred choice for integration into automated process lines, water treatment skids, and chemical dosing systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Diaphragm Valve (2/2-Way, Process & Pneumatic Valve) |
| Model Designation | Type 2030 A 15,0 EA / 00154770 |
| Nominal Line Size | DN 15 (15,0 mm) |
| Actuation Type | Pneumatic piston actuator (spring-return, normally closed/open configurations) |
| Operating Pressure | Standard Industrial Grade (media up to rated bar; pilot air typically 4–7 bar) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (threaded, weld-end, or clamp connections per body variant) |
| Sealing Element | Elastomeric diaphragm (EPDM/PTFE options) for media isolation |
| Body Material | Stainless steel / brass / PVC variants (per model configuration) |
Engineering Features & Advantages
- Precision Performance: The diaphragm sealing principle provides bubble-tight shut-off and eliminates dead pockets, ensuring high-purity and contamination-free media handling with minimal pressure loss.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust pneumatic actuator designed for millions of maintenance-free switching cycles.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, allowing drop-in replacement without modification to existing piping or control interfaces.
- Media Isolation: The diaphragm fully separates the process fluid from the actuator and environment, protecting against corrosion and enabling use with aggressive or sterile media.
- Flexible Automation: Compatible with pilot solenoid valves, position feedback, and control heads for seamless integration into automated process control loops.
Typical Industrial Applications
This pneumatic diaphragm valve is widely deployed in water and wastewater treatment plants, chemical and pharmaceutical processing lines, food and beverage hygienic circuits, and general industrial fluid handling systems. It is also commonly found in dosing and met
PRODUCT IMAGES
BURKERT 2030 A 15,0 EA / 00154770 Pneumatic Diaphragm Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine BURKERT 2030 A 15,0 EA / 00154770 Solenoid Valve. This German-made 24V DC hydraulic component features a direct-acting design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
