Product Overview
The Bürkert Type 2300 A (Part No. 00203568) is a pneumatically operated angle seat valve engineered for precise, high-cycle shut-off and control of neutral and aggressive media in industrial process systems. Manufactured by Bürkert, a global leader in fluid control technology, this valve utilizes a pneumatically actuated piston mechanism acting on a robust valve spindle to deliver fast, repeatable on/off operation. The angle seat design provides an optimized flow path with minimal pressure loss, making it ideal for high-flow applications where reliability and media compatibility are critical. The PTFE (polytetrafluoroethylene) sealing and wetted materials ensure excellent chemical resistance, allowing the valve to handle corrosive fluids, steam, and high-purity media across a wide range of process industries.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatically Operated Angle Seat Valve |
| Model Designation | Bürkert Type 2300 A / 00203568 |
| Operating Pressure | Standard Industrial Grade (Up to rated bar; dependent on orifice size and pilot pressure) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (threaded or flanged process connection) |
| Sealing Material | PTFE (Polytetrafluoroethylene) |
| Actuation Type | Pneumatic piston actuator (single or double acting configuration) |
| Body Configuration | Angle seat (Y-pattern) for optimized flow |
Engineering Features & Advantages
- Precision Performance: The pneumatic piston actuator delivers rapid, consistent valve actuation with short response times, ensuring accurate on/off control and high cycle life in automated process lines.
- PTFE Media Compatibility: PTFE seals and wetted components provide outstanding resistance to aggressive chemicals, steam, and high-purity fluids, extending service intervals and reducing maintenance costs.
- Optimized Angle Seat Design: The angled body geometry minimizes flow resistance and pressure drop, allowing higher flow rates compared to conventional straight-through valves of similar size.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust construction that withstands vibration, thermal cycling, and demanding duty cycles.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Bürkert OEM standards, ensuring drop-in replacement without modification to existing piping or control systems.
Typical Industrial Applications
This Bürkert Type 2300 A angle seat valve is widely deployed in heavy industrial and process environments, including: chemical and petrochemical plants for corrosive media handling; steam and hot water systems in food and beverage processing; pharmaceutical and biotechnology production lines requiring high-purity, cleanable components; water treatment and desalination facilities; and general industrial automation where reliable pneumatic shut-off of neutral or aggressive fluids is essential.
PRODUCT IMAGES
BURKERT 2300 A PTFE / 00203568 Pneumatically Operated Angle Seat Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Burkert 2300 A PTFE / 00203568 Solenoid Valve. This Germany-made 24V DC hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
