Product Overview
The Burkert Type 2702 (Part No. 00210766) is a pneumatically actuated angle seat control valve engineered for precise flow regulation of neutral and aggressive media in industrial process systems. Manufactured by Burkert, a global leader in fluid control technology, this valve utilizes a piston-driven pneumatic actuator acting on a globe-style seat plug, delivering high flow rates with minimal pressure loss through its angled body design. Unlike solenoid or motor-operated valves, the 2702 series provides continuous modulating control via a standard pneumatic control signal, making it ideal for closed-loop process control, dosing, and shut-off duties in demanding industrial environments. The valve’s robust construction and self-adjusting packing gland ensure long service life and reliable sealing across a wide range of temperatures and pressures.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Angle Seat Control Valve (Process & Pneumatic Valve) |
| Model Designation | Burkert 2702 / 00210766 |
| Operating Pressure | Standard Industrial Grade (Up to 16 bar, depending on port size and seal material) |
| Mounting & Connection | Threaded port connections (G ½ to G 2) or weld/clamp ends; actuator with standard air pilot interface |
| Actuation Type | Pneumatic piston actuator (single or double acting) |
| Control Function | Modulating / On-Off (NC, NO, or double-acting configurations) |
| Body Material | Stainless Steel or Gunmetal (dependent on variant) |
| Seal Material | PTFE / EPDM / FKM (media and temperature dependent) |
| Pilot Pressure Range | 3 – 10 bar (typical for pneumatic actuator) |
| Media Temperature | -10 °C to +180 °C (depending on seal material) |
Engineering Features & Advantages
- Precision Flow Control: The angle seat design provides a high flow coefficient (Kv) with minimal pressure drop, enabling accurate modulating control for dosing and process regulation.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust pneumatic piston actuator and self-adjusting packing gland for leak-free performance.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Burkert 2702 series valves, ensuring drop-in replacement without modification.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original BURKERT OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Unlike solenoid or motor-operated valves, the 2702 series provides continuous modulating control via a standard pneumatic control signal, making it ideal for closed-loop process control, dosing, and shut-off duties in demanding industrial environments.
PRODUCT IMAGES
BURKERT 2702 / 00210766 Pneumatic Angle Seat Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Burkert 2702 / 00210766 Direct-Acting Solenoid Valve. This Germany-made 24V DC hydraulic component features a 2/2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
