Product Overview
The BURKERT Type 2702 / 8692 is a pneumatically actuated angle seat control valve engineered for precise regulation of neutral and aggressive media in industrial process lines. Manufactured by Bürkert, a global leader in fluid control technology, this valve combines the proven Type 2702 angle seat valve body with the Type 8692 digital electro-pneumatic positioner, enabling continuous modulating control rather than simple on/off operation. The angled seat geometry delivers high flow rates with minimal pressure loss, while the external pneumatic actuator provides fast, repeatable stroke response. The integrated positioner accepts standard analog control signals and delivers accurate valve positioning for closed-loop process control. This assembly is designed for demanding industrial environments where reliable media shut-off, throttling, and precise flow regulation are essential.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Angle Seat Control Valve (Process & Pneumatic Valve) |
| Model Designation | BURKERT Type 2702 / 8692 |
| Actuation | External pneumatic piston actuator with integrated electro-pneumatic positioner (Type 8692) |
| Control Function | Continuous modulating control (positioning) via analog setpoint signal |
| Valve Body Style | Angle seat (Y-pattern) with straight-through flow path |
| Operating Pressure | Standard industrial process grade (media pressure up to rated bar; pneumatic pilot air typically 4–7 bar) |
| Mounting & Connection | Standard threaded or flanged process connections; NAMUR-style interface between actuator and positioner |
| Position Feedback | Non-contact position sensing with analog and/or digital output signals |
| Seal & Body Materials | Available in stainless steel, brass, or PVC body with PTFE/EPDM/FKM seat seals |
Engineering Features & Advantages
- Precision Modulating Control: The Type 8692 positioner delivers accurate, repeatable valve positioning for throttling and closed-loop flow control, far exceeding simple open/close actuation.
- High Flow with Low Pressure Loss: The angle seat design provides an unobstructed flow path, maximizing flow coefficient (Kv) and minimizing turbulence and pressure drop across the valve.
- Fast Pneumatic Response: The external piston actuator ensures rapid stroke times and high cycle rates, suitable for dynamic process control loops.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and long service life in aggressive media environments.
- Direct Fit Replacement: Precision-manufactured to original BURKERT specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
This assembly is designed for demanding industrial environments where reliable media shut-off, throttling, and precise flow regulation are essential.
PRODUCT IMAGES
BURKERT 2702 / 8692 Pneumatic Angle Seat Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Burkert 2702 / 8692 Solenoid Valve with Position Feedback. This Germany-made 24V DC hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
