The CLIPPARD E315F-2W024 is a heavy-duty industrial micro solenoid valve engineered for precise pneumatic control in compact manifolds and instrumentation circuits. It utilizes a direct-acting, two-way normally-closed configuration with a balanced poppet and wet-pin armature, ensuring consistent response and long cycle life without minimum pressure differential.
CLIPPARD E315F-2W024 Technical Specifications
| Valve Type | 2-Way, Normally Closed, Direct-Acting |
| Orifice Size | 0.032 in |
| Flow Coefficient (Cv) | 0.012 |
| Operating Pressure Range | 0 to 100 psig (0 to 6.9 bar) |
| Coil Voltage | 24 VDC |
| Power Consumption | 2.0 W |
| Port Connection | 10-32 UNF threaded ports |
| Body Material | Stainless Steel |
| Seal Material | FKM (Viton) |
| Response Time | 5 ms (energize), 3 ms (de-energize) |
| Operating Temperature | -10 to 120 °C (14 to 248 °F) |
| Mounting | Manifold or inline |
Key Engineering Features
- Direct-acting poppet design eliminates minimum pressure requirements
- Wet-pin armature construction reduces friction and wear
- Compact 10-32 UNF porting for high-density manifold integration
- Fast 5 ms response time for precise pneumatic sequencing
- Stainless steel body with FKM seals for compatibility with air, inert gases, and selected fluids
- Low 2.0 W power consumption for continuous-duty applications
Industrial Applications
- Medical and laboratory instrumentation
- Analytical equipment and gas chromatography
- Packaging and assembly automation
- Pneumatic pilot circuits and manifold blocks
- Semiconductor processing equipment
- Environmental monitoring and sampling systems
For technical inquiries, dimensional drawings, or replacement support for CLIPPARD E315F-2W024, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
CLIPPARD E315F-2W024 Micro Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the CLIPPARD E315F-2W024 Micro Solenoid Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
