Product Overview
The Danfoss 83044310 axial piston pump is a high-performance, closed-circuit variable displacement unit from the H1P series, designated H1P100L BA A3C3N D3NNN L42L42 SNNN FN 026 NNN. Engineered around a robust swashplate design, this pump converts mechanical input power into precise hydraulic flow with exceptional volumetric and overall efficiency. The H1P100L delivers a nominal displacement of 100 cm³/rev and is purpose-built for demanding industrial and mobile hydraulic systems requiring high pressure capability, accurate displacement control, and long service life. Its advanced servo piston and control architecture enable smooth, responsive regulation of flow and pressure, making it a preferred solution for closed-loop hydrostatic transmission circuits and high-duty-cycle industrial machinery.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Piston Pump (Axial Piston, Variable Displacement) |
| Model Designation | H1P100L BA A3C3N D3NNN L42L42 SNNN FN 026 NNN |
| Manufacturer Part Number | 83044310 |
| Series | Danfoss H1P Series (Closed-Circuit Axial Piston Pump) |
| Nominal Displacement | 100 cm³/rev |
| Operating Pressure | High-Pressure Industrial Grade (Up to 420 bar continuous / 450 bar peak) |
| Control Type | Integral Servo / Displacement Control (per model code configuration) |
| Mounting & Connection | Standard SAE / ISO Flange Interface |
| Rotation | Clockwise / Counter-Clockwise (per model configuration) |
Engineering Features & Advantages
- Precision Swashplate Performance: The axial piston swashplate mechanism delivers precise displacement control with high volumetric efficiency, ensuring stable flow output across the full operating range.
- High-Pressure Capability: Designed for continuous high-pressure operation, the H1P100L supports demanding closed-circuit applications with excellent power density.
- Advanced Displacement Control: Integrated servo control architecture enables fast, accurate response to system commands, optimizing machine cycle times and energy efficiency.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust cylinder barrel, piston, and valve plate construction for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Danfoss OEM standards, ensuring drop-in replacement without modification.
Typical Industrial Applications
The Danfoss H1P
PRODUCT IMAGES
DANFOSS 83044310 / H1P100L BA A3C3N D3NNN L42L42 SNNN FN 026 NNN Axial Piston Pump
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine DANFOSS 83044310 / H1P100L BA A3C3N D3NNN L42L42 SNNN FN 026 NNN Axial Piston Pump. This Denmark-made hydraulic pump features a variable displacement design, delivering reliable fluid power for heavy-duty industrial systems.
