Product Overview
The Danfoss EPV16-B-06-24D-U-13 is a high-performance two-stage proportional cartridge valve engineered for precise electro-hydraulic control of flow and pressure in demanding industrial systems. Operating on a proven proportional solenoid principle, this valve delivers infinitely variable spool positioning proportional to the electrical input signal, enabling smooth, accurate metering of hydraulic fluid. As a cartridge-style component, it is designed for direct installation into a manifold block or integrated hydraulic housing, minimizing external leakage paths and reducing overall system footprint. The EPV16 series is widely recognized for its fast dynamic response, excellent repeatability, and robust construction, making it a preferred choice for closed-loop and open-loop control architectures in modern industrial hydraulics.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Cartridge Valve (Two-Stage, Electro-Hydraulic) |
| Model Designation | EPV16-B-06-24D-U-13 |
| Nominal Size | NG16 (CETOP 16 / ISO 7368 Size 16 Cartridge Cavity) |
| Actuation Type | Proportional Solenoid with Integrated Position Feedback |
| Coil Voltage | 24 VDC (Nominal) |
| Operating Pressure | Up to 350 bar (Standard Industrial Grade) |
| Rated Flow | Up to 160 L/min (dependent on pressure differential and spool configuration) |
| Control Signal Range | 0–10 V / 4–20 mA (via proportional amplifier) |
| Hysteresis | ≤ 3% of nominal stroke |
| Response Time | Fast dynamic response, typically < 30 ms for full stroke |
| Mounting & Connection | ISO 7368 Size 16 Cartridge Cavity, Manifold Mounted |
| Seal Material | NBR (Buna-N) / FKM (Viton) Options Available |
Engineering Features & Advantages
- Precision Performance: The proportional cartridge valve (two-stage, electro-hydraulic) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Danfoss standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 160 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
The EPV16 series is widely recognized for its fast dynamic response, excellent repeatability, and robust construction, making it a preferred choice for closed-loop and open-loop control architectures in modern industrial hydraulics.
PRODUCT IMAGES
Danfoss EPV16-B-06-24D-U-13 Proportional Cartridge Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Danfoss EPV16-B-06-24D-U-13 Proportional Directional Valve. This Denmark-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
