Product Overview
The DANFOSS PRV12-10-S-0-15 is a direct-acting pressure relief valve engineered within the Danfoss PRV series of hydraulic pressure control valves. Operating on a spring-loaded poppet principle, the valve continuously monitors inlet pressure at the P port and opens proportionally once the preset cracking pressure is exceeded, diverting excess flow to the tank port to protect downstream components from overpressure. With a 12-size cavity and a nominal setting of 15 bar, the PRV12-10-S-0-15 serves as a compact, reliable safety and pressure-limiting device in low-pressure hydraulic circuits, pilot lines, and return-line applications where precise, repeatable pressure control is required.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Valve – Pressure Control Valve (Direct-Acting Pressure Relief Valve) |
| Model Designation | PRV12-10-S-0-15 |
| Manufacturer | Danfoss |
| Valve Function | Pressure limiting / relief, direct-acting poppet design |
| Cavity Size | 12-size (industry-standard cartridge cavity) |
| Pressure Setting | 15 bar nominal cracking pressure (factory preset) |
| Operating Pressure | Standard Industrial Grade (up to rated bar per PRV12 series) |
| Adjustment Style | Fixed / preset configuration (S option) |
| Mounting & Connection | Standard ISO / Manufacturer Interface – 12-size cartridge, screw-in installation |
| Seal Material | Standard industrial elastomer seals (NBR/Buna-N compatible) |
| Fluid Compatibility | Mineral-based hydraulic oils, standard industrial hydraulic fluids |
Engineering Features & Advantages
- Precision Pressure Control: Direct-acting poppet design delivers fast, repeatable response to pressure surges, maintaining system pressure at the 15 bar set point with minimal override and hysteresis.
- Compact Cartridge Construction: The 12-size screw-in cartridge format enables space-saving integration into manifold blocks and custom hydraulic power units, reducing piping and leak points.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original DANFOSS standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
With a 12-size cavity and a nominal setting of 15 bar, the PRV12-10-S-0-15 serves as a compact, reliable safety and pressure-limiting device in low-pressure hydraulic circuits, pilot lines, and return-line applications where precise, repeatable pressure control is required.
PRODUCT IMAGES
DANFOSS PRV12-10-S-0-15 Pressure Relief Valve
