Product Overview
The Danfoss SBV11-8-C-0-00 (Part Number: 02-177582) is a high-performance solenoid-operated directional control valve engineered for precise hydraulic flow management in demanding industrial systems. As part of the Danfoss SBV11 series, this valve utilizes a robust spool-and-sleeve design actuated by a wet-armature solenoid, ensuring reliable shifting and positive sealing under high cyclic rates. The “8” designation indicates a nominal flow capacity of 80 L/min, while the “C” spool type provides a closed-center configuration, making it ideal for parallel circuit applications where load holding and precise actuator control are required. This valve serves as a critical interface in hydraulic circuits, directing pressurized fluid to cylinders or motors with minimal pressure drop and exceptional repeatability.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Control Valve |
| Model Designation | SBV11-8-C-0-00 / 02-177582 |
| Operating Pressure | Up to 350 bar (5075 psi) rated working pressure |
| Nominal Flow Rate | 80 L/min (21.1 GPM) at 70 bar delta P |
| Spool Configuration | “C” Type – Closed Center, Parallel Circuit |
| Actuation Method | Wet-armature solenoid, push-pin actuated |
| Mounting & Connection | ISO 4401 / CETOP 3 (NG6) subplate mounting |
| Seal Material | NBR (Buna-N) standard; FKM available on request |
| Electrical Supply | 12 VDC or 24 VDC (dependent on coil variant) |
Engineering Features & Advantages
- Precision Spool & Sleeve: Hardened, precision-ground spool and sleeve assembly ensures minimal internal leakage, low hysteresis, and consistent shift response over millions of cycles.
- Wet-Armature Solenoid Design: The solenoid armature operates in hydraulic fluid, providing superior lubrication, reduced wear, and efficient heat dissipation for high-duty-cycle applications.
- Closed-Center “C” Spool: Blocks all ports in the neutral position, enabling reliable load holding and preventing actuator drift in parallel circuit configurations.
- Industrial Reliability: Constructed with a high-strength cast iron body and corrosion-resistant solenoid housing, built for continuous operation under severe industrial conditions.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Danfoss OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
The “8” designation indicates a nominal flow capacity of 80 L/min, while the “C” spool type provides a closed-center configuration, making it ideal for parallel circuit applications where load holding and precise actuator control are required.
PRODUCT IMAGES
Danfoss SBV11-8-C-0-00 / 02-177582 Solenoid Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Danfoss SBV11-8-C-0-00 / 02-177582 Solenoid Directional Valve. This Denmark-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
