Product Overview
The DANFOSS SV13-12V-C-0-00 (OEM Reference: 02-175828) is a high-performance solenoid-operated directional cartridge valve engineered for precise control of hydraulic fluid flow direction in demanding industrial circuits. Manufactured by Danfoss, a global leader in mobile and industrial hydraulics, this 2-position, 4-way (2/4) spool-type cartridge valve is designed for direct installation into a machined manifold cavity, eliminating the need for external piping and reducing potential leak points. The SV13 series operates on a proven solenoid-actuated spool principle, where an electrical signal energizes the solenoid coil to shift the internal spool, thereby directing pressurized flow from the inlet port to the designated work ports. Its robust cartridge construction allows for high flow capacity relative to its compact size, making it an ideal solution for space-constrained hydraulic power units, integrated manifold blocks, and mobile equipment valve stacks requiring reliable, repeatable directional control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Cartridge Valve (2/4 Spool Type) |
| Model Designation | SV13-12V-C-0-00 / 02-175828 |
| Operating Pressure | Standard Industrial Grade (Up to 350 bar rated) |
| Mounting & Connection | Standard ISO / Manufacturer Cartridge Cavity Interface |
| Actuation Type | 12V DC Solenoid, Wet Armature, Push-Pin Design |
| Flow Direction | 2-Position, 4-Way (P, T, A, B Port Configuration) |
| Spool Configuration | Closed-Center Spool (C-0-00 Designation) |
| Seal Material | Nitrile (Buna-N) / Polyurethane, Standard Industrial |
| Filtration Requirement | ISO 4406 18/16/13 or better |
Engineering Features & Advantages
- Precision Spool Metering: The hardened, precision-ground spool and sleeve assembly ensures minimal internal leakage and accurate flow metering, providing consistent directional control and reliable load holding in closed-center applications.
- Compact Cartridge Design: The screw-in cartridge format allows direct integration into custom manifold blocks, significantly reducing system footprint, eliminating external plumbing, and minimizing potential leak paths compared to conventional subplate-mounted valves.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, the SV13 series features a robust wet-armature solenoid that provides high shifting forces, excellent thermal stability, and long service life even in high-duty-cycle applications.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original DANFOSS OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Manufactured by Danfoss, a global leader in mobile and industrial hydraulics, this 2-position, 4-way (2/4) spool-type cartridge valve is designed for direct installation into a machined manifold cavity, eliminating the need for external piping and reducing potential leak points.
PRODUCT IMAGES
DANFOSS SV13-12V-C-0-00 / 02-175828 Solenoid Directional Cartridge Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Danfoss SV13-12V-C-0-00 / 02-175828 Solenoid Directional Valve. This Denmark-made 12V hydraulic component features a direct-acting spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
