Product Overview
The Eaton Vickers DG4V-3C-6C-M-U-G5-13 (Part Number 6040768-001) is a high-performance, solenoid-operated directional control valve from the globally recognized Vickers DG4V series. Engineered for precise control of hydraulic fluid flow direction, this 3-position, 4-way valve features a closed-center spool configuration (designated by “C” in the model code) and is actuated by a single AC or DC solenoid with spring return. The “M” designation indicates a manual override feature, while “U” specifies a UL-recognized coil. The “G5″ identifies a 5/8” (16 mm) nominal flow path, and “13” denotes the specific spool type and design variant. This valve is a direct-acting, wet-armature design that provides fast response, low pressure drop, and reliable shifting in demanding industrial hydraulic circuits. It serves as a critical control component in systems requiring precise directional control of actuators, motors, and cylinders, ensuring efficient power transmission and safe operation.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Control Valve |
| Model Designation | DG4V-3C-6C-M-U-G5-13 / 6040768-001 |
| Operating Pressure | Up to 350 bar (5075 psi) rated for P, A, B ports; 210 bar (3045 psi) for T port |
| Mounting & Connection | ISO 4401-03 (CETOP 3 / NFPA D03) subplate mounting; 5/8″ nominal flow path |
| Spool Configuration | 3-position, 4-way, closed center (C) |
| Actuation Type | Single solenoid, spring return, manual override (M) |
| Coil Rating | UL recognized (U), 110V AC / 120V AC 50/60 Hz or 24V DC (dependent on coil option) |
| Flow Rate | Up to 40 L/min (10.5 gpm) nominal |
| Fluid Compatibility | Mineral oil, water glycol, phosphate ester (with appropriate seals) |
| Seal Material | Nitrile (Buna-N) standard; Viton available |
Engineering Features & Advantages
- Precision Performance: The solenoid operated directional control valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Precision-manufactured to original Eaton specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
It serves as a critical control component in systems requiring precise directional control of actuators, motors, and cylinders, ensuring efficient power transmission and safe operation.
PRODUCT IMAGES
Eaton Vickers DG4V-3C-6C-M-U-G5-13 / 6040768-001 Solenoid Operated Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine EATON VICKERS DG4V-3C-6C-M-U-G5-13 / 6040768-001 Solenoid Operated Directional Valve. This UK-made 24V DC hydraulic component features a spring-centered, 4-way design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
