Product Overview
The Eaton Vickers KDG4V-3-2C20N-Z-M-U-H7-60 (02-146720) is a high-performance proportional directional valve from the Vickers KDG4V series, engineered for precise electro-hydraulic control of flow direction and magnitude in industrial hydraulic systems. This valve utilizes a proportional solenoid actuator acting on a precision-ground spool within a hardened valve body, enabling infinitely variable flow control proportional to the electrical input signal. The KDG4V-3 platform is a proven, globally recognized design used as a pilot or main-stage control element in demanding motion-control circuits, offering excellent repeatability, low hysteresis, and fast dynamic response. With a CETOP 3 (NG6) mounting interface and a 20 L/min nominal flow rating, this valve is ideally suited for integration into manifold-based systems requiring accurate velocity and position control of hydraulic actuators.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (Vickers KDG4V Series) |
| Model Designation | KDG4V-3-2C20N-Z-M-U-H7-60 / 02-146720 |
| Spool Configuration | 2C — Closed Center, P to A/B with T blocked in neutral |
| Nominal Flow Rating | 20 L/min (NG6 / CETOP 3 size) |
| Operating Pressure | Up to 315 bar (P, A, B ports); T port rated to 160 bar |
| Actuation Type | Proportional solenoid, single-ended with spring return to center |
| Electrical Interface | DIN 43650 / ISO 4400 plug connector (H7 coil rating) |
| Mounting & Connection | CETOP 3 / NG6 / ISO 4401-03 subplate mounting, 4-bolt flange |
| Seal Material | Nitrile (NBR) — suitable for mineral-based hydraulic fluids |
| Fluid Temperature Range | -20 °C to +70 °C (standard NBR seals) |
| Viscosity Range | 10 to 500 cSt (optimal 20–40 cSt) |
Engineering Features & Advantages
- Precision Performance: The proportional directional valve (vickers kdg4v series) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Precision-manufactured to original Eaton specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 20 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a CETOP 3 (NG6) mounting interface and a 20 L/min nominal flow rating, this valve is ideally suited for integration into manifold-based systems requiring accurate velocity and position control of hydraulic actuators.
PRODUCT IMAGES
Eaton Vickers KDG4V-3-2C20N-Z-M-U-H7-60 / 02-146720 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Eaton Vickers KDG4V-3-2C20N-Z-M-U-H7-60 / 02-146720 Solenoid Operated Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
