Product Overview
The Eaton Vickers PVQ13 A2R SE1S 20 C14 12 / 02-341644 is a variable displacement axial piston pump from the renowned Vickers PVQ series, engineered for high-pressure industrial hydraulic systems requiring precise flow control and energy-efficient operation. Utilizing a proven swashplate design with axial piston rotating group, this pump delivers infinitely variable displacement through a pressure-compensator control (SE1S), automatically adjusting output flow to match system demand while maintaining constant pressure. The PVQ13 frame size offers a nominal displacement of approximately 13 cm³/rev, making it ideal for medium-power hydraulic circuits in injection molding machines, machine tools, and industrial presses. Manufactured to Eaton’s stringent quality standards, this pump provides smooth, low-pulsation flow, high volumetric efficiency, and long service life under continuous duty cycles.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Variable Displacement Axial Piston Pump |
| Model Designation | PVQ13 A2R SE1S 20 C14 12 / 02-341644 |
| Series / Frame Size | PVQ13 (13 cm³/rev nominal displacement) |
| Displacement Type | Variable, pressure-compensated (SE1S control) |
| Operating Pressure | Up to 210 bar continuous (3000 psi class) |
| Peak Pressure | Up to 250 bar intermittent |
| Rotation | Clockwise (viewed from shaft end) |
| Mounting & Connection | Standard SAE 2-bolt flange, splined/keyed shaft, SAE port connections |
| Control Type | Pressure compensator with adjustable setting |
| Fluid Compatibility | Mineral-based hydraulic oil, ISO VG 32–68 |
Engineering Features & Advantages
- Precision Swashplate Performance: Axial piston rotating group with hardened swashplate delivers smooth, infinitely variable displacement and high volumetric efficiency across the full pressure range.
- Pressure-Compensated Control (SE1S): Automatically reduces displacement to match load demand, minimizing heat generation and power consumption in idle or holding phases.
- Low Pulsation & Quiet Operation: Optimized piston timing and porting reduce flow ripple and noise, ideal for precision industrial machinery.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Eaton OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
The PVQ13 frame size offers a nominal displacement of approximately 13 cm³/rev, making it ideal for medium-power hydraulic circuits in injection molding machines, machine tools, and industrial presses.
PRODUCT IMAGES
Eaton Vickers PVQ13 A2R SE1S 20 C14 12 / 02-341644 Variable Displacement Axial Piston Pump
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Eaton Vickers PVQ13 A2R SE1S 20 C14 12 / 02-341644 Variable Displacement Piston Pump. This US-made high-pressure hydraulic pump features a variable displacement axial piston design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
