Product Overview
The EDWARDS VS 16K / D059-15-000 is a precision-engineered vacuum solenoid valve designed for reliable isolation and control of vacuum lines in demanding industrial process environments. Manufactured by Edwards Vacuum, a global leader in vacuum technology, this valve operates as an electrically actuated, normally closed (NC) two-port isolation valve. The VS 16K series is specifically engineered for high-vacuum service, utilizing a robust solenoid coil to drive a diaphragm or bellows-sealed poppet mechanism that ensures leak-tight sealing and rapid response. The D059-15-000 part number designates the specific configuration, including the solenoid voltage and port connection standard. This valve is a critical component in vacuum pump inlet isolation, process chamber venting, and load-lock sequencing, providing dependable on/off control that protects vacuum pumps and maintains process integrity in semiconductor, coating, and analytical instrumentation systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Vacuum Solenoid Valve (Process & Pneumatic Valve) |
| Model Designation | EDWARDS VS 16K / D059-15-000 |
| Valve Function | 2/2-way, Normally Closed (NC) isolation |
| Operating Pressure Range | Vacuum service (typically 10-3 mbar to 1 bar absolute) |
| Actuation Type | Direct-acting solenoid, electrically controlled |
| Mounting & Connection | Standard ISO KF / NW flange interface (size dependent on VS 16K series) |
| Seal Material | FKM / Viton elastomer or bellows-sealed stem (application dependent) |
| Body Material | Aluminum or stainless steel construction |
| Response Time | Fast actuation, typically < 50 ms (energization) |
| Electrical Supply | Standard industrial solenoid voltage (e.g., 24 VDC or 230 VAC, per D059 configuration) |
Engineering Features & Advantages
- Precision Vacuum Control: The VS 16K series is purpose-built for high-vacuum isolation, delivering leak-tight sealing and rapid, repeatable actuation that protects vacuum pumps and maintains process chamber integrity.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Precision-manufactured to original EDWARDS specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
This valve is a critical component in vacuum pump inlet isolation, process chamber venting, and load-lock sequencing, providing dependable on/off control that protects vacuum pumps and maintains process integrity in semiconductor, coating, and analytical instrumentation systems.
PRODUCT IMAGES
EDWARDS VS 16K / D059-15-000 Vacuum Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine EDWARDS VS 16K / D059-15-000 Vacuum Solenoid Valve. This UK-made 24V DC hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
