Product Overview
The FESTO LFRS-D-MIDI-A (Part No. 194757) is a high-performance pneumatic filter regulator belonging to FESTO’s renowned D-series air preparation family. This combined unit integrates a centrifugal-type filter with a precision diaphragm pressure regulator in a single compact housing, delivering clean, dry, and accurately regulated compressed air to downstream pneumatic actuators, valves, and control systems. Designed for MIDI-size (G1/4 to G1/2) service, the LFRS-D-MIDI-A features a manual rotary knob with lockable adjustment, a condensate drain, and a high-efficiency filter element that removes solid particles and liquid water droplets from the air stream. As a core component of any industrial pneumatic infrastructure, it ensures stable secondary pressure regardless of fluctuations in the primary supply, protecting sensitive equipment and maximizing process repeatability.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Filter Regulator (Air Preparation Unit) |
| Model Designation | LFRS-D-MIDI-A / 194757 |
| Series / Size | D-Series, MIDI |
| Operating Pressure | Up to 16 bar (primary); regulated secondary 0.5 – 12 bar |
| Pneumatic Connection | G1/4, G3/8, or G1/2 (MIDI port options) |
| Filtration Rating | 40 µm standard element (5 µm optional) |
| Adjustment Type | Manual rotary knob with locking feature |
| Mounting & Connection | Modular mounting per FESTO D-Series; wall bracket or line installation |
| Drain Type | Manual condensate drain (semi-automatic / fully automatic optional) |
| Media | Compressed air (filtered, lubricated or non-lubricated) |
Engineering Features & Advantages
- Precision Performance: The diaphragm-type pressure regulator maintains a constant output pressure with minimal hysteresis and excellent flow characteristics, ensuring repeatable actuator response even under varying load conditions.
- Integrated Filtration & Regulation: Combines particle and condensate removal with pressure control in one compact unit, reducing installation space, piping complexity, and potential leak points.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original FESTO OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
As a core component of any industrial pneumatic infrastructure, it ensures stable secondary pressure regardless of fluctuations in the primary supply, protecting sensitive equipment and maximizing process repeatability.
PRODUCT IMAGES
FESTO LFRS-D-MIDI-A / 194757 Pneumatic Filter Regulator
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine FESTO LFRS-D-MIDI-A / 194757 Filter Regulator. This Germany-made 0.1-16 bar pneumatic component features a combined filter and regulator design, delivering clean, reliable air control for heavy-duty industrial systems.
