The FESTO MEBH-5/3B-D-2-ZSR-C is a heavy-duty industrial pneumatic valve engineered for reliable directional control of compressed air in demanding automation systems. This 5/3-way valve features a closed center spool, providing precise stopping of actuator movement when de-energized. Its robust construction and ISO 5599-1 mounting interface ensure drop-in compatibility with standard manifolds and sub-bases.
FESTO MEBH-5/3B-D-2-ZSR-C Technical Specifications
| Valve Function | 5/3-way, closed center |
| Actuation Type | Electrical, solenoid pilot |
| Operating Pressure Range | 2 to 10 bar |
| Nominal Flow Rate | 1200 l/min |
| Port Size | G1/4 (ISO 228) |
| Mounting Standard | ISO 5599-1, size 2 |
| Electrical Connection | DIN EN 175301-803, type C |
| Operating Voltage | 24 V DC |
| Seal Material | NBR |
| Body Material | Die-cast aluminum |
| Ambient Temperature Range | -5 to +50 °C |
| Protection Class | IP65 |
Key Engineering Features
- 5/3-way closed center spool prevents actuator drift when de-energized
- Solenoid pilot actuation with manual override for commissioning and troubleshooting
- ISO 5599-1 size 2 mounting pattern for direct integration with standard manifolds
- High flow rate of 1200 l/min supports rapid cycling of medium-sized cylinders
- Durable die-cast aluminum body with NBR seals for extended service life
- IP65-rated electrical connection suitable for harsh industrial environments
Industrial Applications
- Automated assembly and handling systems
- Packaging machinery with precise stop-and-hold requirements
- Material transport and sorting equipment
- Machine tools with pneumatic clamping circuits
- Process automation in food and beverage industries
For technical inquiries, dimensional drawings, or replacement support for FESTO MEBH-5/3B-D-2-ZSR-C, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
FESTO MEBH-5/3B-D-2-ZSR-C Pneumatic Valve
