Product Overview
The FESTO MPPES-3-1/8-10-010 is a high-precision proportional pneumatic pressure regulator engineered by Festo for closed-loop pressure control in industrial automation and process systems. Operating on a proportional solenoid actuation principle, this valve continuously modulates its output pressure in direct proportion to an analog electrical setpoint signal (0–10 V or 4–20 mA), enabling stepless, highly dynamic pressure regulation rather than simple on/off switching. With a 1/8″ threaded port connection and a 0–10 bar regulated output range, the MPPES-3-1/8-10-010 serves as a critical control element in pneumatic circuits where precise, repeatable force, torque, or pressure profiling is required. Its integrated closed-loop control electronics compare the actual pressure (via an internal or external sensor) against the commanded setpoint, delivering exceptional accuracy, minimal hysteresis, and fast response times — making it ideal for demanding industrial applications such as tension control, contact pressure regulation, and dynamic force modulation.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pneumatic Pressure Regulator Valve |
| Model Designation | MPPES-3-1/8-10-010 |
| Manufacturer | Festo |
| Operating Pressure Range | 0 to 10 bar regulated output (standard industrial grade) |
| Pneumatic Connection | G1/8 threaded port (ISO 228) |
| Control Signal | Analog setpoint (0–10 V / 4–20 mA), proportional solenoid actuation |
| Control Principle | Closed-loop proportional pressure regulation with integrated electronics |
| Mounting & Connection | Standard Festo modular mounting interface / inline threaded connection |
| Media | Compressed air (filtered, lubricated or non-lubricated) |
Engineering Features & Advantages
- Precision Proportional Control: Stepless pressure regulation proportional to the analog input signal ensures exact, repeatable pressure output with minimal hysteresis and excellent linearity across the full 0–10 bar range.
- Integrated Closed-Loop Electronics: On-board control circuitry continuously compares actual vs. setpoint pressure, delivering fast response times and stable regulation even under varying flow demands.
- Compact G1/8 Design: Space-efficient 1/8″ port configuration allows direct integration into tight pneumatic manifolds and modular Festo valve terminals without additional adapters.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust solenoid actuation and wear-resistant spool/seal design for long service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original FESTO standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
Its integrated closed-loop control electronics compare the actual pressure (via an internal or external sensor) against the commanded setpoint, delivering exceptional accuracy, minimal hysteresis, and fast response times — making it ideal for demanding industrial applications such as tension control, contact pressure regulation, and dynamic force modulation.
PRODUCT IMAGES
FESTO MPPES-3-1/8-10-010 Proportional Pneumatic Pressure Regulator
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine FESTO MPPES-3-1/8-10-010 Pressure Sensor. This Germany-made 0-10 bar pneumatic component features a piezoresistive measuring cell, delivering precise, reliable pressure monitoring for heavy-duty industrial systems.
