Product Overview
The FESTO VPPM-6L-L-1-G18-0L6H-V1N is a precision pneumatic proportional pressure regulator from Festo’s VPPM series, engineered for closed-loop electro-pneumatic pressure control in demanding industrial automation systems. This valve operates on a proportional solenoid principle, where an electrical setpoint signal (0–10 V or 4–20 mA) is continuously compared against an integrated pressure sensor feedback signal, enabling the internal control electronics to modulate the valve spool position and deliver highly accurate, infinitely variable output pressure. With a compact 6 mm nominal width and G1/8 threaded ports, the unit is designed for direct inline mounting within pneumatic control panels and manifold assemblies. Its 0L6H pressure range designation corresponds to a 0–6 bar working range, making it ideally suited for precise force control, tension regulation, and dynamic pressure profiling tasks where conventional on/off or manually adjusted regulators cannot achieve the required repeatability.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Proportional Pressure Regulator Valve |
| Model Designation | VPPM-6L-L-1-G18-0L6H-V1N |
| Manufacturer | Festo |
| Operating Pressure Range | 0 – 6 bar (0L6H pressure range code) |
| Nominal Width | 6 mm (size 6L) |
| Pneumatic Connection | G1/8 threaded ports (supply, working, exhaust) |
| Setpoint Signal | Analog 0–10 V / 4–20 mA (V1N electrical variant) |
| Control Principle | Closed-loop proportional solenoid with integrated pressure feedback |
| Mounting & Connection | Inline / manifold mounting, standard Festo interface |
| Media | Filtered compressed air (lubricated or unlubricated) |
Engineering Features & Advantages
- Precision Proportional Control: The integrated closed-loop pressure control circuit continuously compares the analog setpoint against actual output pressure, delivering highly repeatable and hysteresis-minimized regulation across the full 0–6 bar range.
- Infinitely Variable Setpoint: Accepts standard analog input signals (0–10 V or 4–20 mA), enabling seamless integration with PLC, CNC, and industrial control systems for dynamic pressure profiling.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Precision-manufactured to original FESTO specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
Its 0L6H pressure range designation corresponds to a 0–6 bar working range, making it ideally suited for precise force control, tension regulation, and dynamic pressure profiling tasks where conventional on/off or manually adjusted regulators cannot achieve the required repeatability.
PRODUCT IMAGES
FESTO VPPM-6L-L-1-G18-0L6H-V1N Pneumatic Proportional Pressure Regulator
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine FESTO VPPM-6L-L-1-G18-0L6H-V1N Proportional Pressure Regulator Valve. This German-made pneumatic valve features precise proportional pressure control, delivering reliable and efficient regulation for demanding industrial automation systems.
