Product Overview
The GEA ABF-OD3*-Z-00-MFI-30/3/5-W/43-12J/52 is a sanitary process valve engineered for hygienic fluid handling in food, beverage, dairy, and pharmaceutical production lines. Manufactured by GEA, a global leader in process engineering, this valve operates on a pneumatically actuated, seat-valve working principle, providing reliable on/off and divert control of process media. Its modular design integrates seamlessly into sanitary piping systems, ensuring contamination-free operation and compliance with stringent industry hygiene standards. The valve is designed for direct actuation via a control head or pilot signal, making it a critical component in automated process skids and CIP/SIP circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Sanitary Process Valve (Pneumatic Actuated) |
| Model Designation | ABF-OD3*-Z-00-MFI-30/3/5-W/43-12J/52 |
| Operating Pressure | Standard Industrial Grade (Up to 10 bar / 145 psi, depending on configuration) |
| Mounting & Connection | Standard Sanitary Clamp / DIN / ISO Interface |
| Actuation Type | Pneumatic (Air-to-Open / Air-to-Close options) |
| Body Material | Stainless Steel (AISI 304 / 316L) |
| Seal Material | EPDM / FKM / PTFE (FDA-compliant) |
| Control Signal | 24V DC / 110V AC / 230V AC (via solenoid pilot) |
Engineering Features & Advantages
- Precision Performance: Optimized flow path and seat geometry ensure minimal pressure drop and precise shut-off, maintaining process integrity in critical sanitary applications.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust pneumatic actuation and high-cycle life expectancy.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, allowing drop-in replacement without piping modification.
- Hygienic Design: Fully drainable and cleanable construction, compliant with EHEDG and 3-A sanitary standards for food and pharmaceutical contact.
- Modular Versatility: Interchangeable actuator and seal options enable adaptation to various process media and temperature ranges.
Typical Industrial Applications
This sanitary process valve is widely used in dairy processing (milk, yogurt, cheese production), beverage manufacturing (brewing, soft drinks, juices), pharmaceutical and biotech production (sterile filling, fermentation), and food processing (sauces, soups, ready meals). It is also suitable for CIP/SIP systems, process water treatment, and cosmetic production lines where hygiene and reliability are paramount.
PRODUCT IMAGES
GEA ABF-OD3*-Z-00-MFI-30/3/5-W/43-12J/52 Sanitary Process Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine GEA ABF-OD3*-Z-00-MFI-30/3/5-W/43-12J/52 Solenoid Directional Control Valve. This Germany-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
