Product Overview
The GEMU 673 is a pneumatically actuated diaphragm valve engineered for precise, contamination-free control of neutral, aggressive, and high-purity media in industrial process systems. Manufactured by GEMÜ (Gebrüder Müller Apparatebau), a global leader in fluid handling technology, this valve utilizes a flexible diaphragm as the sole moving wetted component, isolating the working fluid from the actuator and eliminating dead legs, crevices, and seal leakage paths. The GEMU 673 is a direct-acting, normally closed (NC) or normally open (NO) valve with a compact plastic or metal actuator housing, designed for on/off and modulating duty in demanding process environments. Its hermetic separation between media and mechanism makes it ideal for sterile, corrosive, and abrasive applications where cross-contamination and maintenance downtime must be minimized.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Diaphragm Valve (Process & Pneumatic Valve) |
| Model Designation | GEMU 673 |
| Actuation Type | Pneumatic piston actuator, spring-return (NC / NO / DA options) |
| Operating Pressure | Standard Industrial Grade (up to 10 bar media dependent; control air 4–7 bar) |
| Nominal Sizes | DN 10 – DN 50 (½” – 2″) |
| Body Materials | PVC-U, PP, PVDF, ABS (plastic body variants) |
| Diaphragm Materials | EPDM, PTFE/EPDM, FKM (media compatible) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (solvent cement, threaded, or flanged) |
| Media Temperature | Up to 80 °C (material dependent) |
| Control Signal | Pilot air 4–7 bar; optional position feedback and stroke limitation |
Engineering Features & Advantages
- Precision Performance: The diaphragm design provides bubble-tight shutoff and precise flow control with minimal pressure loss, ensuring accurate metering of process media without cavitation or water hammer.
- Hermetic Media Isolation: The diaphragm completely separates the working fluid from the actuator and environment, preventing cross-contamination and enabling use in sterile and high-purity applications.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original GEMU OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its hermetic separation between media and mechanism makes it ideal for sterile, corrosive, and abrasive applications where cross-contamination and maintenance downtime must be minimized.
PRODUCT IMAGES
GEMU 673 Pneumatic Diaphragm Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine GEMU 673 Solenoid Diaphragm Valve. This German-made 24V DC hydraulic component features a direct-acting diaphragm design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
