Product Overview
The GF 161614016 is a precision-engineered plastic process valve from the GF Piping Systems line, designed for reliable flow control in demanding fluid handling and industrial process circuits. As a process valve, it operates through a mechanically actuated sealing mechanism that regulates, isolates, or modulates the flow of compatible media within a piping network. The valve body is constructed from high-grade thermoplastic material, offering excellent chemical resistance and corrosion immunity, making it a direct alternative to metal-bodied valves in aggressive fluid environments. Its compact, lightweight design allows for straightforward integration into both new installations and retrofit applications, while the precision-machined sealing surfaces ensure bubble-tight shutoff and long service life under continuous industrial duty cycles.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Process & Pneumatic Valve (Plastic Process Valve) |
| Model Designation | GF 161614016 |
| Manufacturer | GF Piping Systems |
| Body Material | High-grade thermoplastic (chemical-resistant) |
| Operating Pressure | Standard Industrial Grade (up to rated bar per size) |
| Mounting & Connection | Standard ISO / Manufacturer Interface |
| Actuation Type | Manual / Pneumatic actuation compatible |
| Sealing Principle | Precision-machined sealing surfaces for bubble-tight shutoff |
Engineering Features & Advantages
- Precision Flow Control: Engineered sealing geometry delivers accurate flow regulation and positive isolation, minimizing media loss and process variability.
- Corrosion & Chemical Resistance: Thermoplastic construction eliminates rust and scale buildup, extending service life in aggressive fluid circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with stable performance across repeated actuation cycles.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, ensuring drop-in installation without piping modification.
- Lightweight Construction: Reduced weight compared to metal-bodied equivalents simplifies handling, installation, and structural support requirements.
Typical Industrial Applications
The GF 161614016 plastic process valve is widely deployed in chemical dosing and transfer systems, water and wastewater treatment plants, semiconductor and electronics wet-process lines, and food and beverage fluid handling circuits. It is equally suited to plastic injection molding machine cooling loops, metallurgical process water systems, and marine or offshore fluid control skids where corrosion resistance and reliable shutoff are critical. Its compatibility with pneumatic actuation also makes it a preferred choice for automated process valve manifolds in CNC machine tool coolant management and industrial filtration systems.
PRODUCT IMAGES
GF 161614016 Plastic Process Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine GF 161614016 Solenoid Directional Seat Valve. This German-made hydraulic component features a robust poppet design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
