The Honeywell V9BFW16-100 is a heavy-duty industrial butterfly valve engineered for reliable isolation and throttling of fluids in process and pneumatic systems. It features a wafer-style body with a resilient seat and a lever operator for manual actuation, ensuring tight shutoff and low torque operation.
Honeywell V9BFW16-100 Technical Specifications
| Attribute | Specification |
|---|---|
| Valve Type | Butterfly Valve, Wafer Style |
| Body Material | Cast Iron |
| Disc Material | Stainless Steel |
| Seat Material | EPDM |
| Nominal Size | DN100 (4 inch) |
| Pressure Rating | PN16 |
| End Connection | Wafer, suitable for PN10/PN16 flanges |
| Actuation | Manual Lever |
| Temperature Range | -10°C to 120°C (EPDM) |
| Applications | Water, HVAC, pneumatic, general process |
Key Engineering Features
- Wafer-style body for compact installation between flanges.
- Resilient EPDM seat ensures bubble-tight shutoff.
- Stainless steel disc provides corrosion resistance.
- Lever operator with locking mechanism for secure positioning.
- Low torque operation reduces actuator sizing requirements.
- Designed to meet ISO 5211 mounting standards for actuation upgrades.
Industrial Applications
- HVAC systems for chilled water and heating circuits.
- Pneumatic conveying and compressed air isolation.
- Water treatment and distribution networks.
- General process industries requiring reliable shutoff.
- Cooling towers and pump isolation.
For technical inquiries, dimensional drawings, or replacement support for Honeywell V9BFW16-100, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
Honeywell V9BFW16-100 Butterfly Valve
