Product Overview
The Honeywell V9BFW16-250 is a wafer-style butterfly valve engineered for precise flow regulation and isolation in industrial process and pneumatic systems. Featuring a 16-position manual lever handle, this valve provides incremental flow control across a wide range of media including air, water, and compatible hydraulic fluids. The V9BFW16-250 utilizes a resilient EPDM seat and a precision-machined disc that ensures bubble-tight shutoff and minimal pressure drop during full-flow operation. Its compact wafer design allows for direct installation between standard ANSI flange connections, making it an ideal solution for OEM and MRO applications requiring reliable, quarter-turn actuation in demanding industrial environments.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Butterfly Valve (Process & Pneumatic) |
| Model Designation | V9BFW16-250 |
| Nominal Size | 2-1/2″ (DN65) Wafer Style |
| Operating Pressure | Up to 16 bar (232 psi) rated working pressure |
| Body Material | Cast Iron / Ductile Iron with Epoxy Coating |
| Disc & Stem | Stainless Steel Disc, Blow-out Proof Stem |
| Seat Material | EPDM Resilient Seat (Bubble-tight Shutoff) |
| Actuation | 16-Position Manual Lever Handle (Lockable) |
| Mounting & Connection | Wafer Lug Style, ANSI Class 125/150 Flange Compatible |
| Temperature Range | -20°C to +120°C (EPDM dependent) |
Engineering Features & Advantages
- Precision Flow Metering: The 16-position lever handle enables accurate incremental flow adjustment, allowing operators to fine-tune process parameters without the need for complex actuation systems.
- Bubble-Tight Sealing: The EPDM resilient seat ensures zero-leakage isolation, protecting downstream equipment and preventing costly media loss in pneumatic and hydraulic circuits.
- Low Torque Operation: Precision-machined disc and stem geometry reduce operating torque, enabling smooth quarter-turn actuation and extended seat life.
- Compact Wafer Design: Space-saving wafer body fits between standard flanges, reducing installation footprint and overall system weight compared to flanged alternatives.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original HONEYWELL OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its compact wafer design allows for direct installation between standard ANSI flange connections, making it an ideal solution for OEM and MRO applications requiring reliable, quarter-turn actuation in demanding industrial environments.
PRODUCT IMAGES
HONEYWELL V9BFW16-250 Butterfly Valve
