Product Overview
The HYDAC SAF20M12N210A-S13 (Part No. 2120046) is a precision-engineered accumulator safety block designed to provide safe, reliable isolation and pressure protection for hydraulic bladder, diaphragm, and piston accumulators. As a dedicated pressure control valve assembly, it combines manual shut-off, pressure relief, and unloading functions within a single compact manifold body. The SAF series safety block is a critical safety component in industrial hydraulic systems, ensuring that accumulators can be safely depressurized for maintenance while protecting the circuit against inadmissible pressure spikes. Manufactured by HYDAC, a global leader in fluid power technology, this block is rated for a nominal pressure of 210 bar and features a 12 mm nominal bore size, making it suitable for a wide range of medium-to-high pressure industrial applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Valve – Pressure Control Valve (Accumulator Safety Block) |
| Model Designation | SAF20M12N210A-S13 / 2120046 |
| Nominal Pressure Rating | 210 bar (nominal working pressure) |
| Nominal Bore Size | 12 mm (NG12 connection interface) |
| Function | Manual shut-off, pressure relief, and accumulator unloading |
| Mounting & Connection | Standard ISO / HYDAC manifold interface with threaded ports |
| Sealing Material | NBR (standard); compatible with mineral oil-based hydraulic fluids |
| Body Material | High-strength forged steel / cast iron manifold |
Engineering Features & Advantages
- Integrated Safety Functions: Combines manual shut-off valve, pressure relief valve, and unloading valve in a single compact block, reducing installation space and potential leak points.
- Precision Pressure Control: The relief valve cartridge is factory-set and tamper-resistant, ensuring accurate and repeatable pressure limitation to protect the accumulator and downstream components.
- Safe Depressurization: The manual shut-off feature allows the accumulator to be isolated and safely vented to tank before any maintenance work, meeting stringent industrial safety requirements.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction that withstands pressure spikes and cyclic loading.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original HYDAC SAF series safety blocks, ensuring drop-in replacement without modification.
- Corrosion Resistance: Exterior surfaces are treated with a protective coating to resist environmental corrosion in demanding plant environments.
Typical Industrial Applications
The HYDAC SAF20M12N210A-S13 accumulator safety block is widely deployed in hydraulic systems where accumulator safety and pressure integrity are paramount. Typical applications include plastic injection molding machines, metallurgical presses and rolling mills, construction and marine hyd
PRODUCT IMAGES
HYDAC SAF20M12N210A-S13 / 2120046 Accumulator Safety Block
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine HYDAC SAF20M12N210A-S13 / 2120046 Solenoid Directional Valve. This Germany-made 210 bar hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
