Product Overview
The HYDAC WSM 08130C-01-C-N-22/11 is a direct-acting solenoid directional spool valve engineered for precise control of hydraulic fluid flow direction in industrial power units and machine circuits. Manufactured by HYDAC, a global leader in fluid power technology, this valve utilizes a hardened, precision-ground steel spool reciprocating within a close-tolerance valve body to route flow between ports. Actuated by a wet-pin AC or DC solenoid, the WSM series provides reliable shifting performance and leak-tight sealing in the de-energized or energized state. The 08130C-01-C-N-22/11 configuration is designed for standard industrial mounting interfaces, making it a direct-fit replacement for OEM directional control circuits requiring dependable, repeatable spool positioning.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Spool Valve (Standard Directional Control Valve) |
| Model Designation | WSM 08130C-01-C-N-22/11 |
| Operating Pressure | Standard Industrial Grade (Up to 350 bar rated) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (Subplate or Manifold Mounting) |
| Actuation Type | Solenoid Actuated (Wet-Pin Design) |
| Spool Configuration | Precision-Ground Steel Spool, Closed-Center or Tandem Center Options |
| Flow Direction Control | 4-Way, 3-Position (4/3) Directional Control |
| Seal Material | NBR / FKM (Standard Industrial Hydraulic Fluids) |
| Electrical Connection | DIN 43650 / ISO 4400 Standard Connector |
Engineering Features & Advantages
- Precision Spool Metering: The hardened, precision-ground spool and matched bore deliver accurate flow metering and minimal internal leakage, ensuring consistent actuator response in demanding hydraulic circuits.
- Wet-Pin Solenoid Reliability: The wet-pin solenoid design provides high shifting forces, efficient heat dissipation, and long service life under continuous duty cycles, with manual override available for emergency operation.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, including high cycle rates, pressure spikes, and contaminated fluid environments when properly filtered.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM HYDAC WSM series standards, ensuring drop-in installation without modification to manifolds or subplates.
- Direct Fit Replacement: Precision-manufactured to original HYDAC specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
The 08130C-01-C-N-22/11 configuration is designed for standard industrial mounting interfaces, making it a direct-fit replacement for OEM directional control circuits requiring dependable, repeatable spool positioning.
PRODUCT IMAGES
HYDAC WSM 08130C-01-C-N-22/11 Solenoid Directional Spool Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine HYDAC WSM 08130C-01-C-N-22/11 Solenoid Directional Spool Valve. This German-made 24V DC hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
