Product Overview
The KITZ SCT SCV 10K-3/4 EP (Part No. 750357596) is a high-performance general process control valve engineered by KITZ SCT, a globally recognized manufacturer of precision fluid control components. This valve operates as a direct-acting, pressure-balanced control element designed for precise regulation of process media in demanding industrial circuits. The “10K” designation indicates a nominal pressure rating of 10 kgf/cm² (approximately 1.0 MPa), while the “3/4” denotes a 3/4-inch nominal line size. The “EP” suffix identifies an enhanced-performance trim configuration optimized for extended service life and superior flow characteristics. As a process control valve, it serves as a critical throttling and isolation point within hydraulic and pneumatic systems, enabling accurate modulation of flow rate and pressure without the pulsation or leakage associated with inferior valve designs.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | General Process & Pneumatic Control Valve |
| Model Designation | SCV 10K-3/4 EP / 750357596 |
| Manufacturer | KITZ SCT |
| Nominal Pressure Rating | 10K (10 kgf/cm² / ~1.0 MPa) |
| Nominal Size | 3/4 inch (DN20) |
| Operating Pressure | Standard Industrial Grade (Up to 10 bar rated) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (Threaded or Flanged per 10K Standard) |
| Trim Configuration | EP (Enhanced Performance) Trim |
Engineering Features & Advantages
- Precision Flow Control: The SCV series valve spool and seat geometry are machined to exacting tolerances, delivering linear and repeatable flow metering for accurate process regulation across the full travel range.
- Enhanced Performance (EP) Trim: The EP designation indicates upgraded internal trim materials and surface treatments that resist erosion and corrosion, significantly extending maintenance intervals in aggressive media service.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust body and bonnet assembly that maintains structural integrity under rated pressure and thermal cycling.
- Leak-Tight Shutoff: Precision-lapped seating surfaces ensure minimal internal leakage, providing dependable isolation when the valve is driven to the closed position.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original KITZ SCT OEM standards, ensuring drop-in replacement without modification to existing piping or actuation interfaces.
Typical Industrial Applications
This KITZ SCT control valve is suited for a broad range of heavy industrial scenarios, including: chemical and petrochemical processing plants where precise reagent dosing and flow control are critical; <
PRODUCT IMAGES
KITZ SCT SCV 10K-3/4 EP / 750357596 Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine KITZ SCT SCV 10K-3/4 EP / 750357596 Solenoid Control Valve. This Japan-made 10K pressure-rated hydraulic component features a 2-way normally closed design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
