Product Overview
The MAC PME-502JD is a pneumatically piloted solenoid valve from MAC Valves, engineered for precise directional control of compressed air in industrial automation and process systems. As a member of MAC’s PME series, this valve utilizes a balanced poppet design actuated by a solenoid pilot, delivering fast, repeatable shifting with minimal friction and no dynamic spool seals to wear. The PME-502JD is configured for reliable 4-way directional control, making it suitable for double-acting cylinder actuation, air logic circuits, and general pneumatic process control where consistent response and long service life are critical. Its compact body and industry-standard porting allow direct integration into existing manifolds and OEM pneumatic panels.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Solenoid Valve (Directional Control Valve) |
| Model Designation | PME-502JD |
| Manufacturer | MAC Valves |
| Valve Function | 4-Way, 2-Position (4/2) directional control |
| Actuation Type | Solenoid pilot actuated, spring return |
| Operating Pressure | Standard pneumatic range (approx. 20–150 PSI / 1.4–10 bar) |
| Media | Filtered, lubricated or non-lubricated compressed air |
| Mounting & Connection | Inline / manifold mount with standard MAC porting interface |
| Seal Design | Balanced poppet, no dynamic spool O-rings |
Engineering Features & Advantages
- Balanced Poppet Design: Delivers high flow capacity with fast, consistent shifting and immunity to pressure fluctuations common in pneumatic circuits.
- Frictionless Operation: Absence of dynamic spool seals eliminates stick-slip, reduces wear, and extends service life even in high-cycle automation duty.
- Reliable Solenoid Pilot: Low-power solenoid pilot ensures dependable actuation and quick response for precise directional control.
- Industrial Reliability: Built for continuous operation in demanding factory automation and process environments.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original MAC PME-series OEM standards.
Typical Industrial Applications
The MAC PME-502JD is widely deployed in pneumatic automation and process control systems, including packaging and material handling machinery, automated assembly lines, plastic injection molding equipment, CNC machine tool air circuits, and general industrial valve manifolds requiring fast, repeatable directional control of double-acting actuators.
PRODUCT IMAGES
MAC PME-502JD Pneumatic Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine MAC PME-502JD Solenoid Operated Directional Control Valve. This USA-made 24V DC hydraulic component features a balanced poppet design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
