Product Overview
The MOOG D636-361-0001 / R02JO1M0HXE2-00J1A2 is a high-performance servo proportional valve from the MOOG D636 series, engineered for precise electrohydraulic control of position, velocity, force, and pressure in demanding industrial and motion control systems. Utilizing MOOG’s proven spool-and-sleeve valve architecture with integrated servo-jet pilot actuation, this valve delivers exceptional dynamic response, high resolution, and minimal hysteresis. The D636 platform is a two-stage design in which a low-power electrical command signal drives a torque motor that positions a pilot spool, which in turn controls the main spool through hydraulic amplification. This configuration provides the fast response and fine metering characteristics required for closed-loop control applications, making it a direct fit replacement for OEM servo valve installations in critical industrial machinery.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Servo Proportional Valve (Two-Stage, Spool & Sleeve Design) |
| Model Designation | D636-361-0001 / R02JO1M0HXE2-00J1A2 |
| Manufacturer | MOOG Inc. |
| Operating Pressure | Standard Industrial Grade (Up to 315 bar rated system pressure) |
| Actuation Type | Electrohydraulic — Torque Motor / Servo-Jet Pilot with Main Spool |
| Mounting & Connection | Standard ISO / MOOG Subplate Interface (NG6 / CETOP 3 compatible) |
| Control Signal | Analog Command Input (Voltage or Current, per MOOG standard) |
| Spool Configuration | Four-Way, Three-Position Directional Control Spool |
| Hysteresis & Resolution | < 0.5% (typical MOOG D636 specification) |
| Response Time | High Dynamic Response (suitable for closed-loop servo control) |
Engineering Features & Advantages
- Precision Metering Performance: The spool-and-sleeve design with servo-jet pilot stage delivers extremely fine flow metering, low hysteresis, and high resolution for accurate position, velocity, and force control in closed-loop systems.
- Fast Dynamic Response: The two-stage hydraulic amplification architecture enables rapid spool positioning, making this valve ideal for high-cycle industrial applications requiring quick reaction times and stable control.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original MOOG OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
This configuration provides the fast response and fine metering characteristics required for closed-loop control applications, making it a direct fit replacement for OEM servo valve installations in critical industrial machinery.
PRODUCT IMAGES
MOOG D636-361-0001 / R02JO1M0HXE2-00J1A2 Servo Proportional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine MOOG D636-361-0001 / R02JO1M0HXE2-00J1A2 Servo Valve. This Germany-made 24 VDC hydraulic component features a two-stage design with mechanical feedback, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
