Product Overview
The MOOG D691Z2701G / 080FUAEAVVS2N is a high-performance servo proportional valve from the MOOG D691 series, engineered for precise electrohydraulic control in demanding industrial and mobile applications. Utilizing MOOG’s proven two-stage servo valve design, this unit features a torque-motor pilot stage that drives a precision spool main stage, delivering exceptional dynamic response, minimal hysteresis, and superior flow metering accuracy. The valve is configured with integrated electronics (080FUAEAVVS2N configuration) providing factory-set spool position feedback and closed-loop control for consistent, repeatable performance. As a critical control element in hydraulic systems, it regulates flow direction and magnitude proportional to an electrical command signal, enabling precise velocity, position, and force control of actuators in closed-loop hydraulic circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Servo Proportional Valve (Two-Stage, Torque Motor Pilot) |
| Model Designation | D691Z2701G / 080FUAEAVVS2N |
| Series | MOOG D691 Series |
| Operating Pressure | Up to 350 bar (5,080 psi) rated — standard industrial grade |
| Rated Flow | Nominal 80 L/min at 70 bar valve pressure drop (per 080 code) |
| Pilot Stage | Torque motor with dual nozzle-flapper or jet pilot configuration |
| Main Stage | Precision-ground spool with position feedback (LVDT) |
| Control Signal | Analog ±10 V DC or ±10 mA (integrated electronics) |
| Mounting & Connection | Standard ISO 4401 / CETOP subplate mounting interface |
| Hysteresis | < 0.5% of rated signal (typical MOOG servo valve specification) |
| Response Time | High dynamic response, suitable for closed-loop position/velocity control |
| Seal Material | FKM / NBR (standard hydraulic fluid compatibility) |
Engineering Features & Advantages
- Precision Performance: The servo proportional valve (two-stage, torque motor pilot) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original MOOG standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 80 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
As a critical control element in hydraulic systems, it regulates flow direction and magnitude proportional to an electrical command signal, enabling precise velocity, position, and force control of actuators in closed-loop hydraulic circuits.
PRODUCT IMAGES
MOOG D691Z2701G / 080FUAEAVVS2N Servo Proportional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine MOOG D691Z2701G / 080FUAEAVVS2N Servo Valve. This Germany-made high-performance hydraulic component features a two-stage servo design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
