The MOOG G761-3003 / G19J0GM4VPL is a heavy-duty industrial servo valve engineered for high-response, closed-loop control of position, velocity, and force in demanding hydraulic systems. It features a two-stage design with a dry torque motor and a spool-in-sleeve second stage, providing precise flow control proportional to electrical input.
MOOG G761-3003 / G19J0GM4VPL Technical Specifications
| Parameter | Specification |
|---|---|
| Valve Type | Two-stage electrohydraulic servo valve |
| Mounting Pattern | ISO 4401 / CETOP 5 (NG10) |
| Rated Flow | Up to 40 L/min at 70 bar per land |
| Maximum Operating Pressure | 315 bar (4500 psi) |
| Supply Pressure Range | 14 to 315 bar |
| Hysteresis | < 3% |
| Threshold | < 1% |
| Null Shift | < 2% at 210 bar, 40°C |
| Operating Temperature | -20°C to +80°C |
| Fluid Viscosity Range | 10 to 400 cSt |
| Filtration | ISO 4406 16/13 or better |
| Electrical Connection | 4-pin MS connector |
| Weight | Approx. 2.5 kg |
Key Engineering Features
- Two-stage design with dry torque motor for high dynamic response
- Spool-in-sleeve second stage ensures minimal leakage and precise metering
- High resolution and low hysteresis for accurate closed-loop control
- Rugged construction for continuous industrial duty
- Standard ISO 4401 / CETOP 5 mounting for easy integration
- Field-replaceable pilot stage filter for extended service life
Industrial Applications
- Steel and aluminum rolling mills
- Plastic injection molding machines
- Material testing systems
- Flight simulators and motion platforms
- Gas and steam turbine control
- Heavy-duty robotics and manipulators
For technical inquiries, dimensional drawings, or replacement support for MOOG G761-3003 / G19J0GM4VPL, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
MOOG G761-3003 / G19J0GM4VPL Servo Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the MOOG G761-3003 / G19J0GM4VPL Servo Valve. This precision-engineered industrial component delivers reliable performance and tight fluid control for heavy-duty systems.
