Product Overview
The NACHI SA-G01-C5-C1-31 is a solenoid-operated directional control valve engineered for precise control of hydraulic fluid flow direction in industrial hydraulic circuits. Manufactured by NACHI-FUJIKOSHI, a globally recognized leader in hydraulic component technology, this valve belongs to the SA series of standard directional control valves. It utilizes a robust solenoid actuation mechanism to shift an internal spool, thereby directing pressurized hydraulic fluid to the desired actuator port. The SA-G01-C5-C1-31 is designed for reliable, high-cycle operation and is widely deployed in systems requiring accurate directional control, load holding, and smooth actuator sequencing. Its compact, modular design allows for easy integration into manifold-based and subplate-mounted hydraulic power units.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Control Valve |
| Model Designation | SA-G01-C5-C1-31 |
| Operating Pressure | Standard Industrial Grade (Up to 315 bar rated) |
| Mounting & Connection | Standard ISO / NACHI Subplate Interface (NG6 / CETOP 3) |
| Spool Configuration | C5 / C1 Spool Type (Closed Center, Spring Return) |
| Actuation Method | Single or Dual Solenoid, Wet Armature |
| Max Flow Rate | Up to 40 L/min (dependent on spool position) |
| Electrical Supply | Standard Industrial Voltage (e.g., 24V DC / 110V AC / 220V AC) |
| Seal Material | NBR / FKM (Standard Industrial Hydraulic Fluids) |
Engineering Features & Advantages
- Precision Spool Metering: The SA-G01-C5-C1-31 features a precision-ground spool and sleeve assembly that ensures minimal internal leakage, accurate flow metering, and repeatable directional control for demanding industrial cycles.
- High-Cycle Solenoid Reliability: Equipped with a robust wet-armature solenoid design, this valve delivers consistent actuation force and long service life even under continuous, high-frequency switching operations.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, including high pressure, temperature fluctuations, and contaminated environments common in heavy manufacturing.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM NACHI SA series standards, ensuring drop-in replacement without modification to existing manifolds or subplates.
- Direct Fit Replacement: Precision-manufactured to original NACHI specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
The SA-G01-C5-C1-31 is designed for reliable, high-cycle operation and is widely deployed in systems requiring accurate directional control, load holding, and smooth actuator sequencing.
PRODUCT IMAGES
NACHI SA-G01-C5-C1-31 Solenoid Operated Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine NACHI SA-G01-C5-C1-31 Solenoid Operated Directional Valve. This Japan-made 24V DC hydraulic component features a 4-way 3-position spring-centered design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
