Product Overview
The NORGREN VP5010BJ111H00 is a precision-engineered proportional pneumatic pressure control valve designed for accurate, infinitely variable regulation of downstream air pressure in industrial process systems. As part of the NORGREN VP50 series, this valve operates on a proportional solenoid principle, where the output pressure is directly proportional to the electrical input signal (typically 0–10 V DC or 4–20 mA). This enables closed-loop electronic pressure control with high repeatability and fast dynamic response, making it ideal for applications requiring precise force, torque, or flow modulation in pneumatic actuators and process lines. The VP5010BJ111H00 is a direct-operated, normally closed or normally open configuration (depending on variant), featuring a robust spool-and-sleeve design that ensures minimal hysteresis and excellent linearity. It is a critical component in electro-pneumatic control loops, bridging the gap between digital control systems and pneumatic power circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pneumatic Pressure Control Valve (Process & Pneumatic Valve) |
| Model Designation | VP5010BJ111H00 |
| Operating Pressure | Up to 10 bar (145 psi) inlet; regulated outlet 0–10 bar proportional to signal |
| Control Signal | Analog 0–10 V DC or 4–20 mA (configurable) |
| Port Size & Connection | G1/4 or NPT1/4 (depending on variant); ISO 228 / ANSI standard threads |
| Mounting & Connection | Inline or manifold mounting; standard ISO 5599 interface compatible |
| Body Material | Anodized aluminum alloy with brass internal components |
| Seal Material | NBR (Buna-N) / FKM (Viton) for high-cycle industrial duty |
| Protection Class | IP65 (dust-tight and water-jet protected) |
| Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Engineering Features & Advantages
- Precision Proportional Control: High-resolution spool positioning delivers linear pressure output with minimal hysteresis (<1% typical) and excellent repeatability, ensuring consistent process results.
- Fast Dynamic Response: Direct-acting solenoid design enables rapid pressure modulation, suitable for closed-loop control with PLC or industrial controllers.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original NORGREN standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
It is a critical component in electro-pneumatic control loops, bridging the gap between digital control systems and pneumatic power circuits.
PRODUCT IMAGES
NORGREN VP5010BJ111H00 Proportional Pneumatic Pressure Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine NORGREN VP5010BJ111H00 Solenoid Directional Control Valve. This UK-made 24V DC hydraulic component features a 5/2-way spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
