Product Overview

The NORTHMAN SWH-G02-C6-A240-10 is a high-performance solenoid-operated directional control valve engineered for precise hydraulic circuit switching in industrial machinery. As part of the NORTHMAN SWH-G02 series, this valve utilizes a robust wet-armature solenoid design and a precision-ground spool to direct hydraulic flow with minimal pressure drop and reliable shifting. The “C6” spool configuration provides a closed-center, tandem-type flow path, making it ideal for controlling double-acting cylinders or hydraulic motors where load holding and pump unloading are required. With a 240V AC solenoid coil, this valve is suited for standard industrial control panels and offers dependable, high-cycle operation in demanding hydraulic systems.

Technical Specifications

ParameterSpecification / Feature
Component TypeSolenoid Directional Control Valve
Model DesignationSWH-G02-C6-A240-10
Operating PressureUp to 315 bar (Rated); 350 bar peak
Rated FlowUp to 60 L/min (at 315 bar, 50°C)
Spool TypeC6 – Closed Center, Tandem, Spring Return
Solenoid Voltage240V AC (50/60 Hz)
Mounting & ConnectionISO 4401-03 (CETOP 3 / NFPA D03) Subplate Mounting
Port SizeNG6 (1/4″ to 3/8″ BSPP or SAE)
Seal MaterialNBR (Buna-N) Standard; FKM Optional
Operating Temperature-20°C to +70°C (Ambient); -20°C to +80°C (Fluid)
Filtration RequirementISO 4406 18/16/13 or better

Engineering Features & Advantages

  • Precision Spool & Sleeve: Hardened, ground, and honed spool-to-sleeve clearance ensures minimal internal leakage, precise metering, and long service life even under high-cycle operation.
  • Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
  • Direct Fit Replacement: Precision-manufactured to original NORTHMAN specifications for direct replacement, minimising downtime and eliminating fitment issues.

Typical Industrial Applications

With a 240V AC solenoid coil, this valve is suited for standard industrial control panels and offers dependable, high-cycle operation in demanding hydraulic systems.

PRODUCT IMAGES

NORTHMAN SWH-G02-C6-A240-10
NORTHMAN SWH-G02-C6-A240-10
NORTHMAN SWH-G02-C6-A240-10
NORTHMAN SWH-G02-C6-A240-10
NORTHMAN SWH-G02-C6-A240-10
NORTHMAN SWH-G02-C6-A240-10

NORTHMAN SWH-G02-C6-A240-10 Solenoid Directional Control Valve

⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:

  • Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
  • Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
  • Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
  • Peace of Mind: Covered by our 12-Month Replacement Warranty.

Shop the genuine NORTHMAN SWH-G02-C6-A240-10 Solenoid Directional Control Valve. This Taiwan-made 240V AC hydraulic component features a wet-armature design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
