The NORTHMAN SWM-G02-C4-D12-30-H006 is a heavy-duty industrial directional control valve engineered for precise flow direction and reliable operation in hydraulic circuits. This CETOP 3 / NG6 solenoid-operated valve features a robust wet-pin armature design and a four-way, three-position spool configuration, ensuring consistent performance under demanding pressure and flow conditions.
NORTHMAN SWM-G02-C4-D12-30-H006 Technical Specifications
| Valve Type | Solenoid-operated directional control valve |
| Mounting Standard | CETOP 3 / NG6 / ISO 4401-03 |
| Spool Configuration | 4-way, 3-position (4/3) |
| Spool Function | Closed center (C4) |
| Actuation | Dual solenoid, wet-pin armature |
| Coil Voltage | 12 V DC (D12) |
| Max Operating Pressure | 350 bar (5075 psi) |
| Max Flow Rate | 30 L/min (7.9 gpm) |
| Port Connections | Subplate mounting, ISO 4401-03 |
| Seal Material | NBR (Buna-N) |
| Operating Temperature | -20°C to +80°C |
| Filtration Requirement | ISO 4406 20/18/15 or better |
Key Engineering Features
- Wet-pin armature design reduces wear and ensures consistent shifting force
- High-strength cast iron body for durability in high-cycle applications
- Precision-ground spool and sleeve for minimal internal leakage
- Dual solenoid configuration allows rapid directional change
- Standard CETOP 3 mounting for easy integration into existing manifolds
- 12 V DC coils with high-temperature insulation for reliable operation
Industrial Applications
- Mobile hydraulic systems (construction, agriculture, material handling)
- Industrial power units and test stands
- Machine tool clamping and positioning circuits
- Presses and forming equipment
- Automated assembly and manufacturing lines
For technical inquiries, dimensional drawings, or replacement support for NORTHMAN SWM-G02-C4-D12-30-H006, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
NORTHMAN SWM-G02-C4-D12-30-H006 Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the NORTHMAN SWM-G02-C4-D12-30-H006 Directional Control Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
