Product Overview
The OMFB HDS ISO 34 D(R) directional control valve (part number 601-001-10343) is a high-performance, sectional-type hydraulic directional control valve engineered by OMFB, a recognized manufacturer of precision hydraulic components for mobile and industrial applications. This valve operates on a spool-and-bore principle, where a precision-machined sliding spool is displaced within a honed valve body to route, block, or divert pressurized hydraulic fluid between the pump, actuator, and tank ports. Configured to ISO 4401 / CETOP 03 (NG6) interface standards, the HDS series valve serves as a central control element in hydraulic circuits, enabling precise directional control of single- and double-acting cylinders, hydraulic motors, and rotary actuators. Its robust sectional construction and D(R) spool configuration make it a reliable choice for demanding industrial and mobile hydraulic systems requiring dependable flow direction and load-holding capability.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Directional Control Valve (Sectional / Spool Type) |
| Model Designation | OMFB HDS ISO 34 D(R) / 601-001-10343 |
| Spool Configuration | D(R) Spool Type — Double-Acting, Spring-Centered, Closed-Center |
| Interface Standard | ISO 4401 / CETOP 03 (NG6) Mounting Pattern |
| Operating Pressure | Standard Industrial Grade (Up to 350 bar rated working pressure) |
| Nominal Flow Rate | Up to 60 L/min (dependent on spool position and circuit configuration) |
| Actuation Method | Manual / Mechanical Lever or Solenoid Actuation (per HDS series configuration) |
| Mounting & Connection | Subplate / Manifold Mounting, ISO Standard Port Pattern |
| Seal Material | NBR / FKM (standard industrial hydraulic fluid compatibility) |
| Fluid Compatibility | Mineral-based hydraulic oils (ISO VG 32–68), HL / HLP / HV grades |
Engineering Features & Advantages
- Precision Spool Metering: The D(R) spool configuration delivers accurate, repeatable directional control with defined metering characteristics, ensuring smooth actuator movement and minimized hydraulic shock during direction changes.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OMFB OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its robust sectional construction and D(R) spool configuration make it a reliable choice for demanding industrial and mobile hydraulic systems requiring dependable flow direction and load-holding capability.
PRODUCT IMAGES
OMFB HDS ISO 34 D(R) / 601-001-10343 Hydraulic Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine OMFB HDS ISO 34 D(R) / 601-001-10343 Hydraulic Directional Control Valve. This Italy-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
