Product Overview

The PARKER CPOM3DDV51 is a pilot operated check valve from Parker Hannifin’s CPOM series of modular sandwich valves, designed for direct mounting between a directional control valve and its subplate in ISO 4401 / CETOP 3 (NG6) interface systems. The valve functions as a leak-free load-holding element: in the free-flow direction, hydraulic fluid passes through the poppet with minimal pressure drop, while in the reverse direction the poppet is held seated by the spring and system pressure until a pilot signal acting on the integral pilot piston mechanically lifts the poppet off its seat. This pilot-assisted opening permits controlled reverse flow only when the directional valve is actuated, preventing load drift, cylinder creep, and uncontrolled descent of vertical or suspended loads in the event of a pressure loss, hose rupture, or pump shutdown. The CPOM3DDV51 is a pilot-to-open, single or dual line configuration with a defined pilot ratio and a spring-cracked poppet design, making it a compact, drop-in modular solution for load holding, blocking, and anti-drop circuits in industrial hydraulic power units.

Technical Specifications

ParameterSpecification / Feature
Component TypePilot Operated Check Valve (Modular Sandwich Valve)
Model DesignationCPOM3DDV51
ManufacturerParker Hannifin
Interface StandardISO 4401-03 / CETOP 3 / NG6 modular mounting pattern
Operating PressureStandard industrial grade, up to 350 bar (max. working pressure at ports P, A, B)
Pilot Pressure RatioStandard pilot-to-load ratio (typically 1:3 to 1:5 depending on spring configuration)
Cracking PressureSpring-loaded poppet, low cracking pressure for minimal pressure drop in free flow
Mounting & ConnectionSandwich/modular mounting between directional valve and subplate; standard ISO interface with 4 mounting holes
SealingNBR (Buna-N) O-rings standard; FKM (Viton) available for high-temperature or fire-resistant fluid service
Fluid CompatibilityMineral-based hydraulic oils, HLP/HM grades; consult manufacturer for HFD and water-glycol fluids

Engineering Features & Advantages

  • Precision Performance: The pilot operated check valve (modular sandwich valve) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
  • Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
  • Direct Fit Replacement: Exact dimensional and functional compatibility with original PARKER standards, allowing straightforward retrofit into existing hydraulic systems without rework.

Typical Industrial Applications

The CPOM3DDV51 is a pilot-to-open, single or dual line configuration with a defined pilot ratio and a spring-cracked poppet design, making it a compact, drop-in modular solution for load holding, blocking, and anti-drop circuits in industrial hydraulic power units.

PRODUCT IMAGES

PARKER CPOM3DDV51
PARKER CPOM3DDV51
PARKER CPOM3DDV51

PARKER CPOM3DDV51 Pilot Operated Check Valve

⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:

  • Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
  • Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
  • Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
  • Peace of Mind: Covered by our 12-Month Replacement Warranty.

Shop the genuine PARKER CPOM3DDV51 Solenoid Directional Control Valve. This USA-made hydraulic component features a reliable spool design, delivering leak-free, precise fluid control for heavy-duty industrial systems.
