Product Overview
The Parker D1FBE01CC0NG0019XC001 is a high-performance proportional directional control valve from Parker’s D1FB series, engineered for precise, infinitely variable control of hydraulic actuator direction and velocity in demanding industrial systems. Utilizing a robust spool-and-sleeve design actuated by a high-force proportional solenoid, this valve delivers smooth, stepless flow metering proportional to the electrical command signal, enabling accurate position, velocity, and force control of cylinders and motors. With a nominal size of NG06 (CETOP 3 / ISO 4401-03), the D1FBE01CC0NG0019XC001 integrates seamlessly into standard industrial manifolds and offers exceptional dynamic response, low hysteresis, and excellent repeatability. It is the ideal choice for closed-loop and open-loop applications requiring precise motion control, smooth acceleration profiles, and reliable long-term operation in harsh industrial environments.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Control Valve |
| Model Designation | D1FBE01CC0NG0019XC001 |
| Series | Parker D1FB Series |
| Nominal Size | NG06 (CETOP 3 / ISO 4401-03) |
| Actuation Type | Proportional Solenoid, Single or Dual Solenoid Configuration |
| Spool Type | Closed-Center, Metering Spool with Precise Land Geometry |
| Operating Pressure | Up to 350 bar (5,080 psi) at P, A, B Ports |
| Rated Flow | Up to 40 L/min (nominal at Δp = 35 bar per land) |
| Hysteresis | ≤ 3% of Rated Signal |
| Response Time | ≤ 30 ms (typical, step response) |
| Mounting & Connection | Subplate Mounting per ISO 4401-03 / CETOP 3 Interface |
Engineering Features & Advantages
- Precision Performance: The proportional directional control valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Parker standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
It is the ideal choice for closed-loop and open-loop applications requiring precise motion control, smooth acceleration profiles, and reliable long-term operation in harsh industrial environments.
PRODUCT IMAGES
Parker D1FBE01CC0NG0019XC001 Proportional Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Parker D1FBE01CC0NG0019XC001 Solenoid Directional Control Valve. This Germany-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
