Product Overview

The Parker D1FVE02CC0NL0314 is a high-performance proportional directional control valve from Parker Hannifin’s D1FV series, engineered for precise, infinitely variable control of hydraulic actuator direction and velocity. Utilizing a robust spool-and-sleeve design actuated by a high-force proportional solenoid, this valve delivers smooth, stepless flow metering proportional to the electrical command signal. The D1FVE02CC0NL0314 is a direct-operated, two-stage proportional valve that provides exceptional dynamic response and repeatability, making it an ideal choice for demanding industrial motion control systems requiring accurate position, velocity, and force regulation. As a critical interface between electronic control systems and hydraulic power circuits, it enables sophisticated closed-loop control architectures in a compact, manifold-mounted package.

Technical Specifications

ParameterSpecification / Feature
Component TypeProportional Directional Control Valve
Model DesignationD1FVE02CC0NL0314
SeriesParker D1FV Series
Actuation TypeProportional Solenoid, Direct-Operated
Spool Configuration4-Way, 3-Position, Closed-Center (Tandem/All-Ports-Blocked)
Nominal Flow RateUp to 40 L/min (dependent on pressure drop)
Operating PressureUp to 350 bar (5075 psi) at P, A, B ports; 210 bar (3045 psi) at T port
Control Signal±10 V DC or 4–20 mA (via external amplifier card)
Hysteresis≤ 5% of rated stroke
Response Time≤ 30 ms (typical, 0–100% step)
Mounting & ConnectionISO 4401-03 (CETOP 3 / NG6) Subplate Mounting
Electrical ConnectionDIN 43650 / ISO 4400 Valve Connector

Engineering Features & Advantages

  • Precision Performance: The proportional directional control valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
  • Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
  • Direct Fit Replacement: Exact dimensional and functional compatibility with original PARKER OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
  • Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.

Typical Industrial Applications

As a critical interface between electronic control systems and hydraulic power circuits, it enables sophisticated closed-loop control architectures in a compact, manifold-mounted package.

PRODUCT IMAGES

PARKER D1FVE02CC0NL0314
PARKER D1FVE02CC0NL0314

PARKER D1FVE02CC0NL0314 Proportional Directional Control Valve

⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:

  • Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
  • Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
  • Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
  • Peace of Mind: Covered by our 12-Month Replacement Warranty.

Shop the genuine PARKER D1FVE02CC0NL0314 Solenoid Directional Control Valve. This US-made hydraulic component features a reliable spool design, delivering leak-free, precise fluid control for heavy-duty industrial systems.
