Product Overview
The PARKER D1FVE02CCNME014 is a high-performance proportional directional control valve from Parker’s D1FVE series, engineered for precise, infinitely variable control of hydraulic actuator speed and direction in industrial and mobile hydraulic systems. Utilizing a robust four-way spool design with direct-acting proportional solenoid actuation, this valve delivers smooth, stepless flow metering proportional to the electrical input signal, enabling accurate velocity and position control of cylinders and motors. The D1FVE02CCNME014 is configured with a nominal NG06 (CETOP 3 / ISO 4401-03) interface, making it a direct drop-in solution for compact manifold and subplate mounting applications. Its integrated design supports open-loop proportional control architectures, and when paired with a suitable Parker electronic amplifier (e.g., PWD00A series), it achieves excellent repeatability, low hysteresis, and fast dynamic response for demanding motion control tasks.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Control Valve (4-Way, Spool Type) |
| Model Designation | D1FVE02CCNME014 |
| Manufacturer | Parker Hannifin |
| Nominal Size | NG06 (CETOP 3 / ISO 4401-03) |
| Actuation Type | Proportional Solenoid (Single or Dual Solenoid Configuration) |
| Operating Pressure | Up to 350 bar (P, A, B ports); 210 bar (T port) — Standard Industrial Grade |
| Rated Flow | Approx. 20–40 L/min at Δp = 10 bar (model-dependent spool metering) |
| Spool Type | Proportional metering spool, closed-center or overlapped configuration |
| Hysteresis | ≤ 5% (typical, with matched amplifier) |
| Mounting & Connection | Subplate / Manifold Mounting per ISO 4401-03; DIN 24V DC solenoid connector |
| Electrical Interface | Proportional solenoid, 24V DC nominal, compatible with Parker PWD/PCD amplifiers |
Engineering Features & Advantages
- Precision Performance: The proportional directional control valve (4-way, spool type) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original PARKER OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
The D1FVE02CCNME014 is configured with a nominal NG06 (CETOP 3 / ISO 4401-03) interface, making it a direct drop-in solution for compact manifold and subplate mounting applications.
PRODUCT IMAGES


Explore related inventory
Related parts by brand and category
PARKER D1FVE02CCNME014 Proportional Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine PARKER D1FVE02CCNME014 Solenoid Operated Directional Control Valve. This Germany-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
