The PARKER D1VW002CNTW91 is a heavy-duty industrial directional control valve engineered for precise flow management in demanding hydraulic circuits. Featuring a robust wet-pin solenoid design and a CETOP 3 / NG6 interface, this valve ensures reliable switching and long service life under continuous operation.
PARKER D1VW002CNTW91 Technical Specifications
| Mounting Standard | CETOP 3 / NG6 / ISO 4401-03 |
|---|---|
| Actuation Type | Wet-pin solenoid, AC or DC coil |
| Spool Configuration | Closed center, all ports blocked in neutral |
| Max Operating Pressure | 350 bar (5075 psi) |
| Max Flow Rate | 60 L/min (15.8 gpm) |
| Fluid Compatibility | Mineral oil, HFA/HFB/HFC, synthetic fluids |
| Seal Material | NBR (Buna-N) standard |
| Electrical Connection | DIN 43650 connector |
Key Engineering Features
- Wet-pin solenoid armature eliminates dynamic seals for leak-free operation
- High-strength cast iron body withstands severe industrial environments
- Precise spool-to-bore clearance ensures minimal internal leakage
- Manual override option available for emergency actuation
- Compatible with a wide range of hydraulic fluids and viscosity grades
Industrial Applications
- Machine tool hydraulic power units
- Injection molding and die-casting machinery
- Material handling and lifting equipment
- Presses and metal forming systems
- Mobile and industrial hydraulic manifolds
For technical inquiries, dimensional drawings, or replacement support for PARKER D1VW002CNTW91, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
PARKER D1VW002CNTW91 Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the PARKER D1VW002CNTW91 Directional Control Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
