The PARKER D1VW006ENJW91 is a heavy-duty industrial directional control valve engineered for precise hydraulic flow management in demanding circuits. It utilizes a robust spool-and-sleeve design with a wet-pin armature and solenoid actuation, providing reliable shifting and long service life under continuous pressure. The valve conforms to CETOP 3 / ISO 4401 mounting standards, ensuring direct interchangeability with common manifold and subplate configurations.
PARKER D1VW006ENJW91 Technical Specifications
| Valve Type | Directional Control Valve, Solenoid Operated |
| Mounting Standard | CETOP 3 / ISO 4401 / NFPA D03 |
| Spool Configuration | Closed Center (ENJW91) |
| Actuation | Wet-Pin Solenoid, Single or Dual Coil |
| Max Operating Pressure | 350 bar (5075 psi) |
| Max Flow Rate | 60 L/min (15.8 gpm) |
| Fluid Temperature Range | -20°C to +80°C |
| Coil Voltage | Standard AC/DC options available |
| Seal Material | NBR (Buna-N), FKM optional |
Key Engineering Features
- Wet-pin solenoid design eliminates dynamic seals for reduced wear and leakage
- Closed center spool provides positive load holding and prevents drift
- High-strength cast iron body with precision-machined spool bore
- Manual override option for emergency operation
- Compatible with mineral oil and synthetic hydraulic fluids
Industrial Applications
- Mobile hydraulic systems: excavators, loaders, cranes
- Industrial power units and hydraulic presses
- Material handling and lifting equipment
- Marine and offshore hydraulic control circuits
- Machine tool clamping and positioning systems
For technical inquiries, dimensional drawings, or replacement support for PARKER D1VW006ENJW91, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
PARKER D1VW006ENJW91 Directional Control Valve
