The PARKER D3W002CNJW42 is a heavy-duty industrial directional control valve engineered for precise flow management in demanding hydraulic circuits. Featuring a robust wet-pin solenoid armature and a hardened spool, this valve ensures rapid, reliable shifting and long service life under continuous operation.
PARKER D3W002CNJW42 Technical Specifications
| Mounting Standard | CETOP 3 / ISO 4401-03 / NFPA D03 |
|---|---|
| Configuration | 4-way, 3-position, spring-centered |
| Spool Type | Closed center (all ports blocked in neutral) |
| Actuation | Wet-pin solenoid, single or dual coil |
| Max Operating Pressure | 350 bar (5075 psi) at P, A, B ports |
| Max Flow Rate | 40 L/min (10.5 gpm) |
| Coil Voltage | 12 VDC, 24 VDC, or 110/230 VAC options |
| Protection Class | IP65 with suitable connector |
| Fluid Compatibility | Mineral oil, HFC, HFD, and synthetic fluids |
| Seal Material | NBR (standard), FKM (optional) |
Key Engineering Features
- Wet-pin solenoid design eliminates dynamic seals, reducing wear and leakage risk.
- Hardened, precision-ground spool ensures minimal internal leakage and consistent response.
- Compact CETOP 3 mounting interface for direct manifold or subplate installation.
- High-strength cast iron body withstands severe pressure spikes and vibration.
- Multiple spool options available for customized flow and pressure characteristics.
Industrial Applications
- Mobile hydraulic systems: excavators, loaders, and cranes.
- Industrial presses, injection molding machines, and die-casting equipment.
- Material handling and lifting equipment requiring precise directional control.
- Agricultural machinery and forestry equipment.
- Marine and offshore hydraulic power units.
For technical inquiries, dimensional drawings, or replacement support for PARKER D3W002CNJW42, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
PARKER D3W002CNJW42 Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the PARKER D3W002CNJW42 Directional Control Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
