Product Overview

The PARKER D41FBE01FC1NF0014 is a high-performance proportional directional control valve from Parker’s renowned D41FB series, engineered for precise electro-hydraulic control of flow direction and magnitude in demanding industrial hydraulic systems. Utilizing a robust spool-and-sleeve design actuated by a high-force proportional solenoid, this valve delivers infinitely variable flow control proportional to the electrical input signal, enabling smooth acceleration and deceleration of actuators without pressure spikes or shock loads. The D41FB platform is widely recognized for its exceptional metering characteristics, low hysteresis, and fast dynamic response, making it the ideal choice for closed-loop position, velocity, and force control applications where repeatability and precision are paramount. As a direct-operated proportional valve, the D41FBE01FC1NF0014 provides reliable performance across a broad pressure and flow range, serving as a critical control element in modern industrial automation and mobile hydraulic architectures.

Technical Specifications

ParameterSpecification / Feature
Component TypeProportional Directional Control Valve
Model DesignationD41FBE01FC1NF0014
SeriesParker D41FB Proportional Directional Valve Series
Actuation TypeProportional Solenoid, Direct-Operated
Operating PressureStandard Industrial Grade (Up to 350 bar rated)
Nominal Flow RateSize 01 (NG6 / CETOP 3) — up to 40 L/min dependent on spool configuration
Spool Configuration4-Way, 3-Position, Closed Center (tandem/float options available per model code)
Mounting & ConnectionISO 4401 / CETOP 3 / NG6 Subplate Mounting Interface
Electrical InterfaceProportional solenoid with integrated position feedback (LVDT) — standard DIN connector
Control SignalAnalog ±10 V DC or ±20 mA (via external amplifier card)
Hysteresis< 1% (with closed-loop position feedback)

Engineering Features & Advantages

  • Precision Performance: The proportional directional control valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
  • Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
  • Direct Fit Replacement: Exact dimensional and functional compatibility with original PARKER standards, allowing straightforward retrofit into existing hydraulic systems without rework.
  • Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.

Typical Industrial Applications

As a direct-operated proportional valve, the D41FBE01FC1NF0014 provides reliable performance across a broad pressure and flow range, serving as a critical control element in modern industrial automation and mobile hydraulic architectures.

PRODUCT IMAGES

PARKER D41FBE01FC1NF0014
PARKER D41FBE01FC1NF0014
PARKER D41FBE01FC1NF0014

PARKER D41FBE01FC1NF0014 Proportional Directional Control Valve

⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:

  • Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
  • Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
  • Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
  • Peace of Mind: Covered by our 12-Month Replacement Warranty.

Shop the genuine PARKER D41FBE01FC1NF0014 Solenoid Directional Control Valve. This US-made hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
